Figure 9: Router Secured by Front-Mounng Brackets
8. On the rear of the chassis, slide the rear-mounng brackets on either side of the chassis unl the
rear-mounng brackets contact the rack rails (see Figure 10 on page 10).
The rear-mounng brackets on each side of the chassis are movable. You can adjust the brackets
according to the depth of the rack.
Figure 10: Installing the Rear-Mounng Brackets
9. Install mounng screws into each of the open rear-mounng holes aligned with the rack, starng
from the boom, and secure them ghtly.
10. Visually inspect the alignment of the chassis. If the chassis is installed properly in the rack, all the
mounng screws on one side of the rack are aligned with the mounng screws on the opposite side
and the router is level. Figure 11 on page 11 shows the router fully secured and installed in a four-
post rack.
