Table 41: QSFP+ and QSFP28 Network Port Connector Pinout Informaon
(Connued)
Pin Signal
10 VccRx
11 SCL
12 SDA
13 GND
14 RX3p
15 RX3n
16 GND
17 RX1p
18 RX1n
19 GND
20 GND
21 RX2n
22 RX2p
23 GND
24 RX4n
91
