Table 41: QSFP+ and QSFP28 Network Port Connector Pinout Informaon
(Connued)
Pin Signal
25 RX4p
26 GND
27 ModPrsL
28 IntL
29 VccTx
30 Vcc1
31 Reserved
32 GND
33 TX3p
34 TX3n
35 GND
36 TX1p
37 TX1n
38 GND
92
