Juniper QFX5200 User Manual

CAUTION: Airow In and Airow Out fans and power supplies cannot be mixed in the
same chassis.
Figure 14: QFX5200-32C and QFX5200-32C-L FRU Panel
1—
Management panel
3—
Power supplies
2—
Fan modules
Figure 15: QFX5200-48Y FRU Panel
1—
Power supplies
2—
Fan modules
Fan Modules
The fan modules in QFX5200 devices are hot-insertable and hot-removable eld-replaceable units
(FRUs). These fan modules are designed for one of the two available airow direcons (Airow In or
Airow Out). The fan modules are also color-coded for the airow direcon as well. The fan modules are
installed in the fan module slots on the FRU panel.
The QFX5200-32C and QFX5200-32C-L fan modules have ve fan modules numbered 0 through 4
when counng from le to right.
The QFX5200-48Y fan modules have six fan modules numbered 0 through 5 when counng from le to
right.
