Juniper QFX5200 User Manual

CAUTION: Do not mix power supplies with dierent airow or dierent waage. The
system raises an alarm when a power supply having a dierent airow or waage is
inserted into the chassis.
You may mix AC and DC power supplies with the same airow in QFX5200-48Y, but load sharing is
dierent between the two designs.
Figure 23: 850 W AC Power Supply for QFX5200-32C and QFX5200-32C-L
1—
Handle
3—
AC appliance inlet
2—
Security latch
4—
Ejector lever
Figure 24: 650 W AC Power Supply for QFX5200-48Y
The power supply provides FRU-to-port or port-to-FRU airow depending on the product SKU you
purchase. The power supplies have color-coded indicators to indicate the airow direcon. Either the
PSU handle or the panel behind the handle are color-coded. See Figure 25 on page 41 for an example
40
