Juniper QFX5200 User Manual

of the LEDs on the QFX5200-32C power supply. Figure 27 on page 46 shows the LED locaon on a
QFX5200-48Y power supply.
Figure 26: AC Power Supply LEDs on QFX5200-32C and QFX5200-32C-L Switches
Figure 27: AC Power Supply LED on a QFX5200-48Y Switch
1—
Bi-colored LED
Table 20 on page 46 and Table 21 on page 47 describe the LED behavior on the AC power supplies.
Table 20: AC Power Supply LEDs on QFX5200-32C and QFX5200-32C-L
LED Color State Descripon
AC OK Unlit O The power supply is disconnected from power, or power is not coming into the
power supply.
Green On steadily Power is coming into the power supply.
46
