JUNTTAN PM 20L - Page 24

JUNTTAN Specifications section
24
CAPACITY TABLE, LEADER FOOT ON THE GROUND
Machine type: Piling rig
Machine model: PM 20L
Serial number: 1461
Horizontal slide: Horizontal slide is projected 300, 600, 900 and 1200 mm out.
Counterweight: Weight 6 000 kg (include stabilizers).
1. With tracks in full width and on horizontal, level and firm ground.
2. Counterweight position: full weight.
3. Leader foot and the pile are resting on the ground before inclinations.
4. Stabilizers (optional): Support stabilizers against ground always when
driving backward inclined piles.
5. See Users' Manual for details.
Leader length: 18.6 m + cathead 0.85 m and 4 m telescope.
Leader sections: 13.8 + 4.8 m
Hydraulic hammer: HHK 3AL, total weight 6 400 kg
Maximum pile weights in kg
Pile 18 m
Horizontal
slide
position
Max. 300 mm out Max. 600 mm out Max. 900 mm out Max. 1200 mm out
Inclination
Forw. Backw. Sidew. Forw. Backw. Sidew. Forw. Backw. Sidew. Forw. Backw. Sidew.
1:3 18.43˚
1:3.5 15.94˚
3000 3000 3000 3000
1:4 14.03˚
5500 5500 5500 5000
1:5 11.31˚
5000 6500 5000 6500 5000 6000 5000 5000
1:6 9.46˚
6500 6500 6500 6500 6000 6000 5000 5000
1:8 7.12˚
6500 6500 6500 6500 6000 6000 5000 5000
1:10 5.71˚
6500 6500 6500 6500 6500 6500 6000 6000 5000 5000
1:20 2.86˚
6500 6500 6500 6500 6500 6500 6000 6000 6000 5000 5000 5000
Vertical 0˚
6500 6500 6000 5000
Pile 16 m
Horizontal
slide
position
Max. 300 mm out Max. 600 mm out Max. 900 mm out Max. 1200 mm out
Inclination
Forw. Backw. Sidew. Forw. Backw. Sidew. Forw. Backw. Sidew. Forw. Backw. Sidew.
1:3 18.43˚
3500 3500 3500 3500
1:3.5 15.94˚
5000 5000 5000 5000
1:4 14.03˚
4000 6500 4000 6500 4000 6000 5000
1:5 11.31˚
6500 6500 6500 6500 6000 6000 5000 5000
1:6 9.46˚
6500 6500 6500 6500 6000 6000 5000 5000
1:8 7.12˚
6500 6500 6500 6500 6000 6000 5000 5000
1:10 5.71˚
6500 6500 6500 6500 6500 6500 6000 6000 5000 5000
1:20 2.86˚
6500 6500 6500 6500 6500 6500 6000 6000 6000 5000 5000 5000
Vertical 0˚
6500 6500 6000 5000
