Leader length: 18.6 m + cathead 0.85 m and 4 m telescope.
Leader sections: 13.8 + 4.8 m
Hydraulic hammer: HHK 3AL, total weight 6 400 kg
Maximum pile weights in kg
Pile 14 m
Horizontal
slide
position
Max. 300 mm out Max. 600 mm out Max. 900 mm out Max. 1200 mm out
Inclination
Forw. Backw. Sidew. Forw. Backw. Sidew. Forw. Backw. Sidew. Forw. Backw. Sidew.
1:2.5 21.80˚
2000 2000 2000 2000
1:3 18.43˚
4500 4500 4500 4500
1:3.5 15.94˚
5000 6000 5000 6000 5000 6000 5000
1:4 14.03˚
6500 6500 6500 6500 6000 6000 5000
1:5 11.31˚
6500 6500 6500 6500 6000 6000 5000 5000
1:6 9.46˚
6500 6500 6500 6500 6000 6000 5000 5000
1:8 7.12˚
6500 6500 6500 6500 6000 6000 5000 5000
1:10 5.71˚
6500 6500 6500 6500 6500 6500 6000 6000 5000 5000
1:20 2.86˚
6500 6500 6500 6500 6500 6500 6000 6000 6000 5000 5000 5000
Vertical 0˚
6500 6500 6000 5000
Pile 12 m
Horizontal
slide
position
Max. 300 mm out Max. 600 mm out Max. 900 mm out Max. 1200 mm out
Inclination
Forw. Backw. Sidew. Forw. Backw. Sidew. Forw. Backw. Sidew. Forw. Backw. Sidew.
1:2.5 21.80˚
2000 3000 2000 3000 3000 3000
1:3 18.43˚
5500 5500 5500 5500 5500 5000
1:3.5 15.94˚
6500 6500 6500 6500 6000 6000 5000
1:4 14.03˚
6500 6500 6500 6500 6000 6000 5000
1:5 11.31˚
6500 6500 6500 6500 6000 6000 5000 5000
1:6 9.46˚
6500 6500 6500 6500 6000 6000 5000 5000
1:8 7.12˚
6500 6500 6500 6500 6000 6000 5000 5000
1:10 5.71˚
6500 6500 6500 6500 6500 6500 6000 6000 5000 5000
1:20 2.86˚
6500 6500 6500 6500 6500 6500 6000 6000 6000 5000 5000 5000
Vertical 0˚
6500 6500 6000 5000
