1-6 (No.52114B)
CRT SOCKET P.W. BOARD ASS'Y (SGJ3507A-M2)
K401 QQR0621-002Z FERRITE BEADS
K912 QQR0582-001Z FERRITE BEADS
K916 QQR0582-001Z FERRITE BEADS
K917 QQR0582-001Z FERRITE BEADS
K918 QQR0582-001Z FERRITE BEADS
K920 QQR1139-001 FERRITE BEADS
K931 QQR0582-001Z FERRITE BEADS
K932 QQR0582-001Z FERRITE BEADS
K933 QQR0582-001Z FERRITE BEADS
K935 QQR0582-001Z FERRITE BEADS
K937 QQR0582-001Z FERRITE BEADS
LC601 QQR1199-001 EMI FILTER
LC602 QQR1199-001 EMI FILTER
LC603 QQR1199-001 EMI FILTER
LF901 QQR1159-001 LINE FILTER
LF902 QQR0527-004 LINE FILTER
PC921 PC123Y22 PHOTO COUPLER
RY951 QSK0085-001 RELAY
S421 QSL4A13-C02 LEVER SWITCH V.CENTER
SF101 QAX0723-001 SAW FILTER
TH901 QAD0132-3R0 P THERMISTOR 3
Ω
TU001 QAU0305-001 TUNER
VA901 ERZV10V621CS ZNR
X701 QAX0767-001Z CRYSTAL 8MHz
Ref No. Part No. Part Name Description Local
Q3103 KTA1267/YG/-T TRANSISTOR
Q3105 KTC3199/YG/-T TRANSISTOR
Q3106 KTA1267/YG/-T TRANSISTOR
Q3107 2SA2005/DE/ POW TRANSISTOR
Q3108 2SC5511/DE/ POW TRANSISTOR
Q3109 KTC3199/YG/-T TRANSISTOR
Q3151 KTC3199/YG/-T TRANSISTOR
Q3152 KTA1267/YG/-T TRANSISTOR
Q3301 2SC5083/L-P/-T TRANSISTOR
Q3302 2SC5083/L-P/-T TRANSISTOR
Q3303 2SC5083/L-P/-T TRANSISTOR
Q3304 2SC5147/CDE/F43 POW TRANSISTOR
Q3305 2SC5147/CDE/F43 POW TRANSISTOR
Q3306 2SC5147/CDE/F43 POW TRANSISTOR
Q3351 KTA1267/YG/-T TRANSISTOR
D3101 1SS133-T2 DIODE
D3105 RH1S-T3 SI DIODE
D3106 RH1S-T3 SI DIODE
D3301 1SS133-T2 DIODE
D3302 1SS133-T2 DIODE
D3303 1SS133-T2 DIODE
D3304 1SS82-T2 SI DIODE
D3305 1SS82-T2 SI DIODE
D3306 1SS82-T2 SI DIODE
D3311 MTZJ3.6B-T2 Z DIODE
D3312 1SS133-T2 DIODE
D3313 MTZJ4.3A-T2 Z DIODE
D3314 1SS133-T2 DIODE
D3331 1SS133-T2 DIODE
D3351 1SS133-T2 DIODE
D3352 1SS133-T2 DIODE
D3353 1SS133-T2 DIODE
D3354 1SS133-T2 DIODE
C3101 QETN1HM-106Z E CAPACITOR 10uF 50V M
C3109 QETN1CM-107Z E CAPACITOR 100uF 16V M
C3110 NDC31HJ-221X C CAPACITOR 220pF 50V J
C3111 NDC31HJ-221X C CAPACITOR 220pF 50V J
C3113 QETN2CM-106Z E CAPACITOR 10uF 160V M
C3114 QCB32HK-472Z C CAPACITOR 4700pF 500V K
C3115 QCB32HK-472Z C CAPACITOR 4700pF 500V K
C3117 QETN2CM-106Z E CAPACITOR 10uF 160V M
C3118 QETN0JM-107Z E CAPACITOR 100uF 6.3V M
C3119 QETN1AM-107Z E CAPACITOR 100uF 10V M
C3120 QETN1AM-337Z E CAPACITOR 330uF 10V M
C3121 QCS32HJ-151Z C CAPACITOR 150pF 500V J
C3122 NDC31HJ-5R0X C CAPACITOR 5pF 50V J
C3125 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
C3151 NCB21EK-104X C CAPACITOR 0.1uF 25V K
C3152 NCB21EK-104X C CAPACITOR 0.1uF 25V K
C3301 NDC31HJ-561X C CAPACITOR 560pF 50V J
C3302 NDC31HJ-391X C CAPACITOR 390pF 50V J
C3303 NDC31HJ-561X C CAPACITOR 560pF 50V J
C3321 QETN2EM-105Z E CAPACITOR 1uF 250V M
C3322 QETN2EM-105Z E CAPACITOR 1uF 250V M
C3323 QETN1CM-107Z E CAPACITOR 100uF 16V M
Ref No. Part No. Part Name Description Local
C3351 QETN1CM-107Z E CAPACITOR 100uF 16V M
C3363 QCZ0324-102 C CAPACITOR 1000pF 3kV P
R3108 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R3111 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R3114 QRZ0230-100X UNF C RESISTOR 10
Ω
R3115 NRSA63J-470X MG RESISTOR 47
Ω
1/16W J
R3116 NRSA63J-470X MG RESISTOR 47
Ω
1/16W J
R3117 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R3119 NRSA63J-121X MG RESISTOR 120
Ω
1/16W J
R3122 QRZ9021-561 FUSI RESISTOR 560
Ω
1W J
R3123 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R3124 NRSA63J-390X MG RESISTOR 39
Ω
1/16W J
R3125 NRSA63J-5R6X MG RESISTOR 5.6
Ω
1/16W J
R3126 NRSA63J-563X MG RESISTOR 56k
Ω
1/16W J
R3127 NRSA63J-563X MG RESISTOR 56k
Ω
1/16W J
R3128 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R3129 NRSA63J-5R6X MG RESISTOR 5.6
Ω
1/16W J
R3130 NRSA63J-390X MG RESISTOR 39
Ω
1/16W J
R3131 NRSA63J-121X MG RESISTOR 120
Ω
1/16W J
R3132 QRL029J-391 OMF RESISTOR 390
Ω
2W J
R3134 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R3135 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R3136 NRSA63J-333X MG RESISTOR 33k
Ω
1/16W J
R3139 NRSA63J-681X MG RESISTOR 680
Ω
1/16W J
R3142 NRSA63J-124X MG RESISTOR 120k
Ω
1/16W J
R3143 NRSA63J-681X MG RESISTOR 680
Ω
1/16W J
R3145 NRSA63J-5R6X MG RESISTOR 5.6
Ω
1/16W J
R3146 NRSA63J-5R6X MG RESISTOR 5.6
Ω
1/16W J
R3151 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R3152 NRSA63J-683X MG RESISTOR 68k
Ω
1/16W J
R3153 NRSA63J-683X MG RESISTOR 68k
Ω
1/16W J
R3154 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R3301 NRSA63J-151X MG RESISTOR 150
Ω
1/16W J
R3302 NRSA63J-151X MG RESISTOR 150
Ω
1/16W J
R3303 NRSA63J-151X MG RESISTOR 150
Ω
1/16W J
R3304 NRSA63J-121X MG RESISTOR 120
Ω
1/16W J
R3305 NRSA63J-121X MG RESISTOR 120
Ω
1/16W J
R3306 NRSA63J-121X MG RESISTOR 120
Ω
1/16W J
R3307 NRSA63J-470X MG RESISTOR 47
Ω
1/16W J
R3308 NRSA63J-470X MG RESISTOR 47
Ω
1/16W J
R3309 NRSA63J-470X MG RESISTOR 47
Ω
1/16W J
R3310 QRL029J-153 OMF RESISTOR 15k
Ω
2W J
R3311 QRL029J-153 OMF RESISTOR 15k
Ω
2W J
R3312 QRL029J-153 OMF RESISTOR 15k
Ω
2W J
R3313 QRL029J-183 OMF RESISTOR 18k
Ω
2W J
R3314 QRL029J-183 OMF RESISTOR 18k
Ω
2W J
R3315 QRL029J-183 OMF RESISTOR 18k
Ω
2W J
R3316 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R3317 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R3318 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R3325 QRZ0107-102Z C RESISTOR 1k
Ω
1/2W K
R3326 QRZ0107-102Z C RESISTOR 1k
Ω
1/2W K
R3327 QRZ0107-102Z C RESISTOR 1k
Ω
1/2W K
R3331 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R3332 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R3333 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R3334 NRSA63J-152X MG RESISTOR 1.5k
Ω
1/16W J
R3335 NRSA63J-271X MG RESISTOR 270
Ω
1/16W J
R3336 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R3337 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R3338 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R3351 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R3352 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R3353 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R3354 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
L3301 QQL244K-180Z COIL 18uH K
L3302 QQL244K-180Z COIL 18uH K
L3303 QQL244K-180Z COIL 18uH K
L3304 QQL244K-470Z COIL 47uH K
L3305 QQL244K-470Z COIL 47uH K
L3306 QQL244K-470Z COIL 47uH K
CN3004 QJB003-073226 SIN ID C-B WIRE
CN3005 WJA0029-001A E-S ID WIRE
CN300V QGA2501C5-03Z CONNECTOR W-B (1-3)
CN30E2 QUB130-38A6AS SIN TWIST WIRE
CN30E4 QUB130-38A6AS SIN TWIST WIRE
FR3122 QRZ9021-561 FUSI RESISTOR 560
Ω
1W J
HS3010 CEHP00N-001QS HEAT SINK
HS3011 CEHP00N-001QS HEAT SINK
HS3012 CEHP00N-001QS HEAT SINK
HS3013 CEHP00N-001QS HEAT SINK
HS3014 CEHP00N-001QS HEAT SINK
K3102 QQR1114-001Z FERRITE BEADS
K3103 QQR1114-001Z FERRITE BEADS
K3104 QQR1114-001Z FERRITE BEADS
K3105 QQR1114-001Z FERRITE BEADS
Ref No. Part No. Part Name Description Local
