(No.52114B)1-7
AV SELECTOR P.W. BOARD ASS'Y (SGJ-5505A-M2)
SK3001 QNZ0536-001 CRT SOCKET
Ref No. Part No. Part Name Description Local
IC5001 CXA2134Q-X IC
IC5151 NJM2150AD IC
IC5201 TC90A49AP IC
IC5501 TA1218AN IC
Q5001 2SA1530A/QR/-X SI TRANSISTOR
Q5002 2SA1530A/QR/-X SI TRANSISTOR
Q5211 2SC3928A/QR/-X SI TRANSISTOR
Q5212 2SC3928A/QR/-X SI TRANSISTOR
Q5251 2SC3928A/QR/-X SI TRANSISTOR
Q5252 2SA1530A/QR/-X SI TRANSISTOR
Q5253 2SA1530A/QR/-X SI TRANSISTOR
Q5261 2SA1530A/QR/-X SI TRANSISTOR
Q5262 2SC3928A/QR/-X SI TRANSISTOR
Q5263 2SA1530A/QR/-X SI TRANSISTOR
Q5384 DTC323TK-X DIGI TRANSISTOR
Q5385 DTC323TK-X DIGI TRANSISTOR
Q5386 DTC323TK-X DIGI TRANSISTOR
Q5387 DTC323TK-X DIGI TRANSISTOR
Q5501 2SA1530A/QR/-X SI TRANSISTOR
D5391 MTZJ9.1C-T2 Z DIODE
D5392 MTZJ9.1C-T2 Z DIODE
D5501 MTZJ9.1C-T2 Z DIODE
D5502 MTZJ9.1C-T2 Z DIODE
D5503 MTZJ9.1C-T2 Z DIODE
D5505 MTZJ9.1C-T2 Z DIODE
D5507 MTZJ9.1C-T2 Z DIODE
D5508 MTZJ9.1C-T2 Z DIODE
D5509 MTZJ9.1C-T2 Z DIODE
D5510 MTZJ9.1C-T2 Z DIODE
D5511 MTZJ9.1C-T2 Z DIODE
D5512 MTZJ9.1C-T2 Z DIODE
D5513 MTZJ9.1C-T2 Z DIODE
C5001 QENC1HM-475Z BP E CAPACITOR 4.7uF 50V M
C5002 NCB31HK-562X C CAPACITOR 5600pF 50V K
C5003 NCB31HK-123X C CAPACITOR 0.012uF 50V K
C5004 QETN1HM-105Z E CAPACITOR 1uF 50V M
C5005 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C5006 QETN1HM-106Z E CAPACITOR 10uF 50V M
C5007 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C5008 QETN1CM-107Z E CAPACITOR 100uF 16V M
C5009 QENC1HM-475Z BP E CAPACITOR 4.7uF 50V M
C5010 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C5011 QENC1HM-475Z BP E CAPACITOR 4.7uF 50V M
C5012 NCB31HK-272X C CAPACITOR 2700pF 50V K
C5013 NCB31HK-473X C CAPACITOR 0.047uF 50V K
C5014 QENC1HM-475Z BP E CAPACITOR 4.7uF 50V M
C5015 QETN1HM-106Z E CAPACITOR 10uF 50V M
C5016 QETN1HM-105Z E CAPACITOR 1uF 50V M
C5017 QENC1HM-105Z BP E CAPACITOR 1uF 50V M
C5018 QENC1HM-105Z BP E CAPACITOR 1uF 50V M
C5019 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C5020 NCB31HK-472X C CAPACITOR 4700pF 50V K
C5021 QENC1HM-475Z BP E CAPACITOR 4.7uF 50V M
C5022 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C5023 NCB31HK-472X C CAPACITOR 4700pF 50V K
C5024 QENC1HM-475Z BP E CAPACITOR 4.7uF 50V M
C5025 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C5026 QETN1HM-335Z E CAPACITOR 3.3uF 50V M
C5031 QETN1HM-106Z E CAPACITOR 10uF 50V M
C5151 QENC1HM-105Z BP E CAPACITOR 1uF 50V M
C5152 QENC1HM-105Z BP E CAPACITOR 1uF 50V M
C5153 NCB31HK-222X C CAPACITOR 2200pF 50V K
C5154 NCB31HK-222X C CAPACITOR 2200pF 50V K
C5155 NCB31HK-473X C CAPACITOR 0.047uF 50V K
C5156 NCB31HK-473X C CAPACITOR 0.047uF 50V K
C5157 QETN1HM-106Z E CAPACITOR 10uF 50V M
C5158 QETN1HM-106Z E CAPACITOR 10uF 50V M
C5159 QETN1EM-476Z E CAPACITOR 47uF 25V M
C5160 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C5203 QETN1EM-476Z E CAPACITOR 47uF 25V M
C5204 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5205 QETN1EM-476Z E CAPACITOR 47uF 25V M
C5206 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5211 QENC1CM-106Z BP E CAPACITOR 10uF 16V M
C5212 NDC31HJ-101X C CAPACITOR 100pF 50V J
C5213 NDC31HJ-470X C CAPACITOR 47pF 50V J
C5214 NDC31HJ-181X C CAPACITOR 180pF 50V J
Ref No. Part No. Part Name Description Local
C5215 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C5226 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5231 QETN1CM-107Z E CAPACITOR 100uF 16V M
C5232 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5233 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5234 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5235 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5236 QETN1CM-107Z E CAPACITOR 100uF 16V M
C5237 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5238 QETN1CM-107Z E CAPACITOR 100uF 16V M
C5239 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5240 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5241 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5242 QETN1CM-107Z E CAPACITOR 100uF 16V M
C5243 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5246 NDC31HJ-181X C CAPACITOR 180pF 50V J
C5247 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5251 QETN1EM-476Z E CAPACITOR 47uF 25V M
C5252 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5253 NDC31HJ-820X C CAPACITOR 82pF 50V J
C5255 NDC31HJ-470X C CAPACITOR 47pF 50V J
C5263 NDC31HJ-470X C CAPACITOR 47pF 50V J
C5391 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C5392 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C5501 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C5502 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C5503 QETN1HM-106Z E CAPACITOR 10uF 50V M
C5504 QETN1HM-106Z E CAPACITOR 10uF 50V M
C5506 QETN1HM-106Z E CAPACITOR 10uF 50V M
C5508 QETN1HM-106Z E CAPACITOR 10uF 50V M
C5509 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5520 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C5521 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C5531 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5532 QETN1EM-476Z E CAPACITOR 47uF 25V M
C5533 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5534 QENC1CM-106Z BP E CAPACITOR 10uF 16V M
R5001 NRSA63J-105X MG RESISTOR 1M
Ω
1/16W J
R5002 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R5003 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R5004 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R5005 NRSA63F-623X MG RESISTOR 62k
Ω
1/16W F
R5007 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R5008 NRSA63J-302X MG RESISTOR 3k
Ω
1/16W J
R5010 NRSA63J-392X MG RESISTOR 3.9k
Ω
1/16W J
R5011 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R5012 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R5031 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R5032 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R5033 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R5034 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R5151 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R5152 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R5153 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R5154 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R5156 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R5158 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R5159 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R5210 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R5211 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R5212 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R5213 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R5214 NRSA63J-181X MG RESISTOR 180
Ω
1/16W J
R5215 NRSA63J-152X MG RESISTOR 1.5k
Ω
1/16W J
R5216 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R5217 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R5240 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R5241 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R5242 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R5243 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R5251 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R5253 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R5254 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R5255 NRSA63J-681X MG RESISTOR 680
Ω
1/16W J
R5258 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R5259 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R5261 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R5262 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R5263 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R5265 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R5269 NRSA63J-681X MG RESISTOR 680
Ω
1/16W J
R5270 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R5384 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R5385 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R5386 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R5387 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R5391 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R5392 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
Ref No. Part No. Part Name Description Local
