JVC AV-27FA44/BSA - FRONT CONTROL P.W. BOARD ASSY (SGJ-6504 A-M2); LED & POWER SW P.W. BOARD ASSY (SGJ-7503 A-M2)

1-8 (No.52114B)
FRONT CONTROL P.W. BOARD ASS'Y (SGJ-6504A-M2)
LED & POWER SW P.W. BOARD ASS'Y (SGJ-7503A-M2)
R5393 NRSA63J-823X MG RESISTOR 82k Ω 1/16W J
R5394 NRSA63J-823X MG RESISTOR 82k Ω 1/16W J
R5395 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R5396 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R5501 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R5502 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R5503 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R5504 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R5505 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R5507 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R5508 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R5509 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R5510 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R5511 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R5512 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R5513 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R5514 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R5515 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R5516 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R5517 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R5519 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R5520 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R5521 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R5522 NRSA63J-224X MG RESISTOR 220k
Ω 1/16W J
R5523 NRSA63J-224X MG RESISTOR 220k Ω 1/16W J
R5524 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R5526 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R5527 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R5532 NRSA63J-224X MG RESISTOR 220k Ω 1/16W J
R5533 NRSA63J-224X MG RESISTOR 220k Ω 1/16W J
R5541 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R5542 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R5543 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R5544 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R5545 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R5546 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R5558 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R5559 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R5560 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R5561 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R5564 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R5565 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
L5202 QQL244K-150Z COIL 15uH K
L5211 QQL244K-4R7Z COIL 4.7uH K
L5241 QQL244K-4R7Z COIL 4.7uH K
L5243 QQL244K-4R7Z COIL 4.7uH K
L5244 QQL244K-4R7Z COIL 4.7uH K
L5261 QQL244K-150Z COIL 15uH K
CN5001 QGB1505K1-35 CONNECTOR B-B (1-35)
CN5006 QGA2501C5-05Z CONNECTOR W-B (1-5)
J5501 QNZ0454-001 AV JACK S/V/L/R IN
J5502 QNN0349-001 PIN JACK V/L/R IN
J5503 QNN0348-001 PIN JACK L/R OUT
 Ref No. Part No. Part Name Description Local
C6401 QETN1HM-106Z E CAPACITOR 10uF 50V M
C6402 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C6403 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
R6401 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R6402 NRSA63J-224X MG RESISTOR 220k Ω 1/16W J
R6403 NRSA63J-224X MG RESISTOR 220k
Ω 1/16W J
R6702 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6703 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R6704 NRSA63J-152X MG RESISTOR 1.5k
Ω 1/16W J
R6705 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R6706 NRSA63J-562X MG RESISTOR 5.6k
Ω 1/16W J
CN6006 QJB003-054010 SIN ID C-B WIRE
CN6007 QJB003-064426 SIN ID C-B WIRE
CN600B QJB003-050806 SIN ID C-B WIRE
J6401 QNN0281-003 PIN JACK V IN
J6402 QNN0281-002 PIN JACK L IN
J6403 QNN0282-001 PIN JACK R IN
LC6401 QQR1199-001 EMI FILTER
S6702 QSW0619-003Z TACT SWITCH MENU
S6703 QSW0619-003Z TACT SWITCH CH-
S6704 QSW0619-003Z TACT SWITCH CH+
S6705 QSW0619-003Z TACT SWITCH VOL-
S6706 QSW0619-003Z TACT SWITCH VOL+
 Ref No. Part No. Part Name Description Local
 Ref No. Part No. Part Name Description Local
IC7701 GP1UM281QK IR DETECT UNIT 38kHz
Q7702 UN2112-X TRANSISTOR
D7701 LG22440 LED POWER
C7701 QETN1EM-476Z E CAPACITOR 47uF 25V M
R7708 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R7709 NRSA63J-561X MG RESISTOR 560 Ω 1/16W J
R7710 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R7711 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
CN700B QGA2501C5-05Z CONNECTOR W-B (1-5)
S7701 QSW0847-001 TACT SWITCH POWER
