3. Setting method. (Fig.3~ Fig.7)
(1) [CH/] keys
Select the SETTING ITEM
(2) [VOL/] keys
Setting the SETTING VALUE of the SETTING ITEM
When the key is released the SETTING VALUE will be stored (memorized).
(3) [EXIT] key
Return to the previous screen.
4. Releasing the SERVICE MENU
(1) After returning to the SERVICE MENU upon completion of the setting work, press the [EXIT] key again.
1.V/C(S), 2.DEF(D)
RF 4 : 3 STD LOW
SETTING NO.
RECEIVING MODE
(RF/EXT/COMP)
ASPECT MODE
(4:3 / 16:9)
SETTING ITEM
SETTING VALUE
3.AUDIO(A)
SETTING NO.
SETTING ITEM
SETTING VALUE
A01 IN LEVEL
Fig.3 Fig.4
VIDEO STATUSE
(STD / THEA)
WHITE BALANCE
(LOW / HIGH)
(S:signal / D:DEF)
10.VCO
TUNER
HIGH LEVEL
REFERENCE LEVEL
LOW LEVEL
SYNC :YES
MAIN
Fig.7
AFC LEVEL
SYNC INPUT
8.HIGH LIGHT7.LOW LIGHT
BRIGHT
G CUTOFF B CUTOFF
R CUTOFF
B DRIVER DRIVE
Fig.5 Fig.6
SETTING VALUESETTING VALUE
SETTING VALUESETTING ITEM
The settings for LOW LIGHT and HIGH LIGHT are described in the WHITE BALANCE page of ADJUSTMENT PROCEDURE.
The setting for VCO is described in the IF VCO page of ADJUSTMENT PROCEDURE.
