JVC DD-8E - Removing the Tray Assembly

(No.MB563)1-31
3.3.6 Removing the Tray assembly
(See Fig.12, 13)
(1) Remove the one screw H attaching the shaft guide from
bottom side. (See Fig.12)
(2) Remove the two screws J attaching the shaft guide from
top side. (See Fig.13)
Fig.12
Fig.13
H
[bottom side]
J
