JVC DD-8E - Page 73

3-15
Audio board
Block No. [0][2]
 Symbol No. Part No. Part Name Description Local
IC200 R2S15902FP IC
IC201 NJM4565M-WE IC
IC202 NJM4565M-WE IC
IC203 NJM4565M-WE IC
IC204 NJM4565M-WE IC
IC205 CD4066BM-X IC
IC221 NJM4565M-WE IC
IC231 NJM4565M-WE IC
IC261 GP1FAV30TK0F OPT TRANSMITTER
IC271 GP1FAV30RK0F OPT RECEIVER
IC561 GP1UM271XKVF IR DETECT UNIT
IC601 MM1623XF-X IC
Q2021 KTA1504/YG/-X TRANSISTOR
Q2022 KTA1504/YG/-X TRANSISTOR
Q2023 KTC3875/YG/-X TRANSISTOR
Q2024 KTC3875/YG/-X TRANSISTOR
Q2025 KTC3875/YG/-X TRANSISTOR
Q2032 KRA104S-X DIGI TRANSISTOR
Q2035 KRC104S-X TRANSISTOR
Q2036 KRC104S-X TRANSISTOR
Q2101 KTC3875/YG/-X TRANSISTOR
Q2201 KTC3875/YG/-X TRANSISTOR
Q2601 2SD2114K/VW/-X TRANSISTOR
Q2602 2SD2114K/VW/-X TRANSISTOR
Q2801 KRA104S-X DIGI TRANSISTOR
Q2803 IMX9-W TRANSISTOR
Q2804 IMX9-W TRANSISTOR
Q2805 IMX9-W TRANSISTOR
Q2806 KRA104S-X DIGI TRANSISTOR
Q2807 KRA104S-X DIGI TRANSISTOR
Q2808 KRA104S-X DIGI TRANSISTOR
Q2901 KTC3203/OY/-T TRANSISTOR
Q5601 KRC102S-X DIGI TRANSISTOR
Q5602 KTC3875/YG/-X TRANSISTOR
Q5661 KTC3875/YG/-X TRANSISTOR
Q6451 KRA102S-X DIGI TRANSISTOR
Q6452 KRC102S-X DIGI TRANSISTOR
Q6453 KRC102S-X DIGI TRANSISTOR
Q6454 KRC102S-X DIGI TRANSISTOR
D2051 MTZJ6.2C-T2 Z DIODE
D2701 MTZJ5.6B-T2 Z DIODE
D2821 1SS133-T2 SI DIODE
D2822 1SS133-T2 SI DIODE
D2823 1SS133-T2 SI DIODE
D2901 MTZJ11A-T2 Z DIODE
D5661 SELU1E54CM-P LED
D5801 SLR-343VC/NPQ-T LED
D5802 SELU1E54CM-P LED
C2021 QETN1HM-104Z E CAPACITOR 0.1uF 50V M
C2022 NDC31HJ-470X C CAPACITOR 47pF 50V J
C2023 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C2024 QETN1HM-107Z E CAPACITOR 100uF 50V M
C2025 NDC31HJ-100X C CAPACITOR 10pF 50V J
C2026 NCB31HK-471X C CAPACITOR 470pF 50V K
C2027 NCB31HK-221X C CAPACITOR 220pF 50V K
C2028 QETN1HM-106Z E CAPACITOR 10uF 50V M
C2029 NCB31HK-333X C CAPACITOR 0.033uF 50V K
C2030 NCB31HK-473X C CAPACITOR 0.047uF 50V K
C2033 NDC31HJ-100X C CAPACITOR 10pF 50V J
C2051 NCB31HK-102X C CAPACITOR 1000pF 50V K
C2052 NCB31HK-221X C CAPACITOR 220pF 50V K
C2053 NCB31HK-221X C CAPACITOR 220pF 50V K
C2061 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2063 QETN1EM-476Z E CAPACITOR 47uF 25V M
C2071 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2073 QETN1EM-476Z E CAPACITOR 47uF 25V M
C2101 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2102 QETN1HM-105Z E CAPACITOR 1uF 50V M
C2103 QTE1J60-106Z E CAPACITOR 10uF 63V
C2104 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2105 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C2106 QFG32AJ-393 PP CAPACITOR 0.039uF 100V J
C2107 QFVF1HJ-154Z MF CAPACITOR 0.15uF 50V J
C2108 QFG32AJ-223Z PP CAPACITOR 0.022uF 100V J
C2109 QTE1J60-106Z E CAPACITOR 10uF 63V
C2110 QTE1J60-106Z E CAPACITOR 10uF 63V
C2111 QTE1J60-106Z E CAPACITOR 10uF 63V
C2112 NFV41HJ-151X MPPS CAPACITOR 150pF 50V J
C2113 QTE1J60-106Z E CAPACITOR 10uF 63V
C2114 NDC31HJ-101X C CAPACITOR 100pF 50V J
C2115 QTE1J60-106Z E CAPACITOR 10uF 63V
C2116 QEKC1HM-225Z E CAPACITOR 2.2uF 50V M
C2131 NDC31HJ-560X C CAPACITOR 56pF 50V J
C2132 QETN1AM-227Z E CAPACITOR 220uF 10V M
C2133 QFLC1HJ-272Z M CAPACITOR 2700pF 50V J
C2134 QFLC1HJ-272Z M CAPACITOR 2700pF 50V J
C2141 NCB31HK-331X C CAPACITOR 330pF 50V K
C2142 QETN1HM-105Z E CAPACITOR 1uF 50V M
C2145 QETN1HM-106Z E CAPACITOR 10uF 50V M
C2146 QETN1HM-106Z E CAPACITOR 10uF 50V M
C2147 QEKC1HM-225Z E CAPACITOR 2.2uF 50V M
C2148 QFG32AJ-682Z PP CAPACITOR 6800pF 100V J
DD3B,
DD3E,
DD3E
N,DD
3EV,D
D3EE
C2201 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2202 QETN1HM-105Z E CAPACITOR 1uF 50V M
C2203 QTE1J60-106Z E CAPACITOR 10uF 63V
C2204 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2205 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C2206 QFG32AJ-393 PP CAPACITOR 0.039uF 100V J
C2207 QFVF1HJ-154Z MF CAPACITOR 0.15uF 50V J
C2208 QFG32AJ-223Z PP CAPACITOR 0.022uF 100V J
C2209 QTE1J60-106Z E CAPACITOR 10uF 63V
C2210 QTE1J60-106Z E CAPACITOR 10uF 63V
C2211 QTE1J60-106Z E CAPACITOR 10uF 63V
C2212 NFV41HJ-151X MPPS CAPACITOR 150pF 50V J
C2213 QTE1J60-106Z E CAPACITOR 10uF 63V
C2214 NDC31HJ-101X C CAPACITOR 100pF 50V J
C2215 QTE1J60-106Z E CAPACITOR 10uF 63V
C2216 QEKC1HM-225Z E CAPACITOR 2.2uF 50V M
C2231 NDC31HJ-560X C CAPACITOR 56pF 50V J
C2232 QETN1AM-227Z E CAPACITOR 220uF 10V M
C2233 QFLC1HJ-272Z M CAPACITOR 2700pF 50V J
C2234 QFLC1HJ-272Z M CAPACITOR 2700pF 50V J
C2241 NCB31HK-331X C CAPACITOR 330pF 50V K
C2242 QETN1HM-105Z E CAPACITOR 1uF 50V M
C2245 QETN1HM-106Z E CAPACITOR 10uF 50V M
C2246 QETN1HM-106Z E CAPACITOR 10uF 50V M
C2247 QEKC1HM-225Z E CAPACITOR 2.2uF 50V M
C2248 QFG32AJ-682Z PP CAPACITOR 6800pF 100V J
DD3B,
DD3E,
DD3E
N,DD
3EV,D
D3EE
C2301 QTE1J60-106Z E CAPACITOR 10uF 63V
C2302 QTE1J60-106Z E CAPACITOR 10uF 63V
C2303 NFV41HJ-151X MPPS CAPACITOR 150pF 50V J
C2304 QTE1J60-106Z E CAPACITOR 10uF 63V
C2305 QEKC1HM-225Z E CAPACITOR 2.2uF 50V M
C2306 NDC31HJ-101X C CAPACITOR 100pF 50V J
C2307 QTE1J60-106Z E CAPACITOR 10uF 63V
C2308 QFLC1HJ-272Z M CAPACITOR 2700pF 50V J
C2401 QTE1J60-106Z E CAPACITOR 10uF 63V
C2402 QTE1J60-106Z E CAPACITOR 10uF 63V
C2403 NFV41HJ-151X MPPS CAPACITOR 150pF 50V J
C2404 QTE1J60-106Z E CAPACITOR 10uF 63V
C2405 QEKC1HM-225Z E CAPACITOR 2.2uF 50V M
C2406 NDC31HJ-101X C CAPACITOR 100pF 50V J
C2407 QTE1J60-106Z E CAPACITOR 10uF 63V
C2408 QFLC1HJ-272Z M CAPACITOR 2700pF 50V J
C2501 QTE1J60-106Z E CAPACITOR 10uF 63V
C2503 QTE1J60-106Z E CAPACITOR 10uF 63V
C2506 QTE1J60-106Z E CAPACITOR 10uF 63V
C2507 QTE1J60-106Z E CAPACITOR 10uF 63V
C2511 QFLC1HJ-272Z M CAPACITOR 2700pF 50V J
C2601 QTE1J60-106Z E CAPACITOR 10uF 63V
 Symbol No. Part No. Part Name Description Local
