JVC DD-8E - Page 76

3-18
Lan board
Block No. [0][3]
CN201 QGF1036F2-18 CONNECTOR FFC/FPC (1-18)
CN202 QGB1214J1-20S CONNECTOR B-B (1-20)
CN204 QGA2016F1-15 CONNECTOR W-B (1-15)
CN561 QGF1036F2-19 CONNECTOR FFC/FPC (1-19)
CN562 QGA2016F1-08 CONNECTOR W-B (1-8)
CN601 QGF1036C2-07 CONNECTOR FFC/FPC (1-7)
CN603 QGF1036C2-19 CONNECTOR FFC/FPC (1-19)
DI561 QLF0178-001 FL TUBE
FW581 QUM214-08Z4Z4-E PARA RIBON WIRE
J2101 QNN0735-001 PIN JACK
J2102 QND0118-001 DIN CONNECTOR
J6401 QNZ0625-001 RGB CONNECTOR
J6701 QNN0675-001 PIN JACK
K2061 QQR0621-001Z COIL
K2071 QQR0621-001Z COIL
K5601 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
S5501 QSW0683-001Z PUSH SW
S5502 QSW0683-001Z PUSH SW
S5503 QSW0683-001Z PUSH SW
S5504 QSW0683-001Z PUSH SW
S5505 QSW0683-001Z PUSH SW
S5506 QSW0683-001Z PUSH SW
S5507 QSW0683-001Z PUSH SW
S5511 QSW0683-001Z PUSH SW
 Symbol No. Part No. Part Name Description Local
IC801 IP3023BG228250U IC(MCU)
IC811 DM9161AEP IC
IC821 K4S281632I-UC60 IC(DIGITAL)
IC831 SG16A90TFIR1 IC
IC841 MM1663DH-X IC
IC851 MM1701CH-X IC
D8001 SML-310VT/JK/-X LED
D8002 SML-310PT/KL/-X LED
C8001 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8002 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8010 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8011 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8012 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8014 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8015 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8016 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8017 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8018 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8019 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8020 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8021 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8022 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8023 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8024 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8025 NEAF0JM-107X E CAPACITOR 100uF 6.3V M
C8026 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8027 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8028 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8029 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8030 NEAF0JM-107X E CAPACITOR 100uF 6.3V M
C8031 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8032 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8033 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8034 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8035 NDC31HJ-100X C CAPACITOR 10pF 50V J
C8036 NDC31HJ-100X C CAPACITOR 10pF 50V J
C8037 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8039 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8040 NEAF0JM-107X E CAPACITOR 100uF 6.3V M
C8041 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8042 NEAF0JM-107X E CAPACITOR 100uF 6.3V M
 Symbol No. Part No. Part Name Description Local
C8043 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C8044 NCB31HK-102X C CAPACITOR 1000pF 50V K
C8045 NCB31HK-102X C CAPACITOR 1000pF 50V K
C8046 NCB31HK-102X C CAPACITOR 1000pF 50V K
C8047 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8048 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8049 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8052 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8053 NEAF0JM-107X E CAPACITOR 100uF 6.3V M
C8055 NDC31HJ-330X C CAPACITOR 33pF 50V J
C8101 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C8102 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8103 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C8104 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C8105 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8106 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8107 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8108 NDC31HJ-220X C CAPACITOR 22pF 50V J
C8109 NDC31HJ-220X C CAPACITOR 22pF 50V J
C8110 NEAF0JM-107X E CAPACITOR 100uF 6.3V M
C8111 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8112 NCB31CK-105X C CAPACITOR 1uF 16V K
C8113 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8114 NCB31CK-105X C CAPACITOR 1uF 16V K
C8115 NCZ1030-102X C CAPACITOR 1000pF
C8116 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8117 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8201 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8202 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8203 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8204 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8205 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8206 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8207 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8208 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8209 NEAF0JM-107X E CAPACITOR 100uF 6.3V M
C8301 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8302 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8303 NEAF0JM-107X E CAPACITOR 100uF 6.3V M
C8401 NCB31HK-333X C CAPACITOR 0.033uF 50V K
C8402 NEAF0JM-226X E CAPACITOR 22uF 6.3V M
C8403 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C8405 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C8501 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C8503 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C8505 NCF31AZ-105X C CAPACITOR 1uF 10V Z
R8001 NRSA63J-330X MG RESISTOR 33 Ω 1/16W J
R8005 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R8006 NRSA63J-154X MG RESISTOR 150k
Ω 1/16W J
R8007 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R8008 NRSA63J-512X MG RESISTOR 5.1k
Ω 1/16W J
R8009 NRSA63J-512X MG RESISTOR 5.1k
Ω 1/16W J
R8022 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R8023 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R8024 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R8025 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R8026 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R8027 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R8101 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R8103 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R8104 NRSA63F-682X MG RESISTOR 6.8k Ω 1/16W F
R8105 NRSA63J-510X MG RESISTOR 51
Ω 1/16W J
R8106 NRSA63J-510X MG RESISTOR 51
Ω 1/16W J
R8107 NRSA63J-510X MG RESISTOR 51 Ω 1/16W J
R8108 NRSA63J-510X MG RESISTOR 51
Ω 1/16W J
R8109 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R8110 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R8111 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R8112 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R8113 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R8201 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R8202 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R8301 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
L8002 NQR0350-001X FERRITE BEADS
CN801 QGF0536C7-45W CONNECTOR FFC/FPC (1-45)
