Connector board
Block No. [0][5]
WC103 QZW0112-001 WIRE CLAMP
WC301 QZW0112-001 WIRE CLAMP
WC302 QZW0112-001 WIRE CLAMP
Symbol No.
Part No. Part Name Description Local
IC201 LA6502-X IC
IC301 ES8381FCC IC
IC302 MM1701EH-X IC
IC305 MM1663DH-X IC
IC306 MM1565AF-X IC
IC309 TC74VHC574FT-X IC
IC310 TC74VHC574FT-X IC
IC311 TC74LVX138FT-X IC(DIGITAL)
IC312 SN74LVC1G125V-X IC
IC453 S-80830CNNB-G-W IC
IC505 K4S281632F-UC60 IC(DIGITAL)
IC505 or K4S281632I-UC60 IC(DIGITAL)
IC509 SG16A90TFIR1 IC
IC510 BR24L16F-W-X IC(DIGITAL)
IC701 AK4387ET-X IC
IC702 AK4387ET-X IC
IC703 AK4387ET-X IC
IC704 AK5358ET-X IC
IC705 MM1615AN-X IC
IC706 NJM4565M-WE IC
IC801 SII9030CTU IC
IC802 SN74CB3T3306U-X IC
IC804 MM3141JN-X IC
IC805 MM3143DN-X IC
IC806 LD2981ABM50-X IC
Q101 KTA1001/Y/-X TRANSISTOR
Q101 or 2SB1424/R/-W TRANSISTOR
Q103 KTA1001/Y/-X TRANSISTOR
Q103 or 2SB1424/R/-W TRANSISTOR
Q801 2SB709A/RS/-X TRANSISTOR
Q802 2SD601A/RS/-X TRANSISTOR
Q803 2SD601A/RS/-X TRANSISTOR
D301 UDZW5.6B-X Z DIODE
D302 UDZW5.6B-X Z DIODE
D305 RB521S-30-X SB DIODE
D801 NAF0013-001X ESD SUPPRESSOR V
D802 NAF0013-001X ESD SUPPRESSOR V
D803 BAV99L-X SI DIODE
C101 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C102 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C103 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C104 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C105 NEAF0JM-476X E CAPACITOR 47uF 6.3V M
C106 NBE20JM-226X TA E CAPACITOR 22uF 6.3V M
C107 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C108 NBE20JM-226X TA E CAPACITOR 22uF 6.3V M
C109 NCB31HK-102X C CAPACITOR 1000pF 50V K
C110 NCB31HK-102X C CAPACITOR 1000pF 50V K
C111 NEAF0JM-476X E CAPACITOR 47uF 6.3V M
C201 NDC31HJ-221X C CAPACITOR 220pF 50V J
C202 NDC31HJ-221X C CAPACITOR 220pF 50V J
C203 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C204 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C205 NDC31HJ-121X C CAPACITOR 120pF 50V J
C208 NCB31HK-561X C CAPACITOR 560pF 50V K
C210 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C211 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C217 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C251 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C253 NCB31HK-561X C CAPACITOR 560pF 50V K
C255 NCB31CK-153X C CAPACITOR 0.015uF 16V K
C256 NCB31CK-104X C CAPACITOR 0.1uF 16V K
Symbol No.
Part No. Part Name Description Local
C257 NCB31HK-822X C CAPACITOR 8200pF 50V K
C258 NCB31CK-153X C CAPACITOR 0.015uF 16V K
C259 NCB31CK-153X C CAPACITOR 0.015uF 16V K
C260 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C261 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C262 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C263 NEAF1CM-107X E CAPACITOR 100uF 16V M
C271 NCB31HK-561X C CAPACITOR 560pF 50V K
C274 NCB31HK-561X C CAPACITOR 560pF 50V K
C301 NDC31HJ-6R0X C CAPACITOR 6pF 50V J
C302 NDC31HJ-6R0X C CAPACITOR 6pF 50V J
C303 NCF21CZ-225X C CAPACITOR 2.2uF 16V Z
C304 NCF21CZ-225X C CAPACITOR 2.2uF 16V Z
C305 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C306 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C307 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C308 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C309 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C310 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C311 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C312 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C313 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C314 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C315 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C316 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C317 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C318 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C319 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C320 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C321 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C322 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C323 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C324 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C325 NCB31HK-681X C CAPACITOR 680pF 50V K
C326 NCB31HK-681X C CAPACITOR 680pF 50V K
C327 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C328 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C329 NEAF0GM-476X E CAPACITOR 47uF 4V M
C330 NCB31HK-102X C CAPACITOR 1000pF 50V K
C331 NDC31HJ-101X C CAPACITOR 100pF 50V J
C332 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C333 NDC31HJ-101X C CAPACITOR 100pF 50V J
C334 NDC31HJ-101X C CAPACITOR 100pF 50V J
C335 NCB31HK-472X C CAPACITOR 4700pF 50V K
C336 NCB31HK-102X C CAPACITOR 1000pF 50V K
C337 NCB31AK-154X C CAPACITOR 0.15uF 10V K
C338 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C339 NEAF0GM-476X E CAPACITOR 47uF 4V M
C340 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C341 NEAF0GM-476X E CAPACITOR 47uF 4V M
C342 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C344 NEAF0GM-476X E CAPACITOR 47uF 4V M
C345 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C347 NEAF0GM-476X E CAPACITOR 47uF 4V M
C348 NEAF0GM-476X E CAPACITOR 47uF 4V M
C349 NCB31HK-271X C CAPACITOR 270pF 50V K
C350 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C351 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C353 NDC31HJ-101X C CAPACITOR 100pF 50V J
C354 NCF31CZ-474X C CAPACITOR 0.47uF 16V Z
C355 NCF31CZ-474X C CAPACITOR 0.47uF 16V Z
C356 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C358 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C359 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C360 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C361 NEAF1CM-106X E CAPACITOR 10uF 16V M
C362 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C363 NDC31HJ-390X C CAPACITOR 39pF 50V J
C364 NDC31HJ-390X C CAPACITOR 39pF 50V J
C371 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C372 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C380 NCB21CK-105X C CAPACITOR 1uF 16V K
C381 NCF21CZ-225X C CAPACITOR 2.2uF 16V Z
C382 NCB31HK-471X C CAPACITOR 470pF 50V K
C383 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C390 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C391 NCB21AK-225X C CAPACITOR 2.2uF 10V K
C392 NCB31HK-471X C CAPACITOR 470pF 50V K
Symbol No.
Part No. Part Name Description Local
