JVC EX-A3 User Manual

50
Reference
When a JVC-manufactured TV with AV COMPU
LINK II or III terminals is connected to the main
unit using these terminals, operating either the TV
or the main unit controls the other device at the
same time.
NOTE
• Some JVC-manufactured TVs have terminals
labeled “AV COMPU LINK”. These terminals are
the same as the [AV COMPU LINK] terminal on
the main unit of this system or, the “AV COMPU
LINK I/II” or “AV COMPU LINK” terminal on other
JVC-manufactured systems.
• Refer to “OTHERS” on page 43 for determining
the “AV COMPULINK MODE” setting.
• Also refer to the manual of the TV to be con-
nected to the main unit.
• The AV COMPU LINK function may not work for
some TVs when the main unit is connected to
the TV via the video 2 or video 3 terminal on the
TV.
1 Turn on the main power of the TV.
2 Play back a disc/file.
• Refer to pages 21–23.
• The power of the TV is turned on.
• The input mode on the TV changes to either
the video 1, video 2 or video 3 (DVD) input.
Preparation for the AV
COMPU LINK function
Input terminal on the
TV
“AV COMPULINK
MODE” setting
Video 1 DVD2
Video 2 DVD3
Video 3 DVD1
JVC-manufac-
tured TV
Connection cable
(not supplied)
Main unit (rear view
)
AV COMPU
LINK
II or III
Operating the AV COMPU
LINK function
Using the AV COMPU LINK function
EX-A3[J_C].book Page 50 Wednesday, December 27, 2006 3:53 PM

JVC EX-A3 Specifications

General

RMS rated power	80 W
Number of speakers	2
Type	Home audio micro system
Cassette deck	No
Optical disc player	Yes
Audio formats supported	MP3, WAV, WMA
Image formats supported	JPG
Tuner type	Digital
Supported radio bands	AM, FM
Preset stations quantity	45
Media types supported	MP3/WMA/WAV/JPEG, MPEG-4 (ASF)/DivX(R)
Headphone outputs	1

Weight and Dimensions

Weight	2700 g
Main speaker width	143 mm
Main speaker height	257 mm
