JVC GY-HM150U User Manual

18
Preparations
Set the date/time of the built-in clock in the [Initial Setting]
screen. The configured date/time data is saved in the built-in
rechargeable battery even if the power is turned off.
Setting the Clock in the [Initial Setting]
Screen
The [Initial Setting] screen appears when the power is turned
on for the first time and when the built-in battery is turned on
again after being fully discharged.
All operations are disabled until initial settings are complete.
1 Turn on the power.
The [Initial Setting] screen appears.
 For GY-HM150U
 For GY-HM150E
2 Specify [Time Zone] and [Date/Time].
A Move the cursor with the set lever (H I) and select the
setting item.
B Change the values with the set lever (JK).
3 Press the center of the set lever after setting is
complete.
The clock is set to 0 seconds of the input date/time.
Memo :
● The configured date/time data can be displayed on the LCD
monitor and viewfinder and be recorded to the SDHC/SDXC
card.
● The value of the year can be set in the range of A 2000 B to
A 2063 B .
Changing the Time after Initial Setting
 Setting the date/time (A Page 74)
1 Select [Others] menu B [Date/Time].
The [Date/Time] setting screen appears.
2 Set the date and time.
A Move the cursor with the set lever (H I) and select the
setting item.
B Change the values with the set lever (JK).
3 Press the center of the set lever after setting is
complete.
The clock is set to 0 seconds of the input date/time.
Changing the Display Style
You can change the display style of the date/time on the
menu.
Memo :
● To perform the settings while looking at the monitor screen
connected to the video signal output terminal, set [Display
On TV] in the [A/V Out] menu to A On B . ( A Page 73)
 Setting the date style (Date Style) (A Page 72)
A
Select [LCD/VF] menu B[Status Display] menu B[Date
Style].
B Select the date display style.
[Setting values: YMD (year, month, day), MDY (month,
day, year), DMY (day, month, year)]
C Press the center of the set lever.
Setting the Clock (Initial
Setting)
DC
REC
PUSH
OIIS
SHUTTER
MENU/
THUMB
T
W
REC
AE ±
ADJ./ VOL.
P
R
O
G
R
A
M
A
E
Set Lever
[MENU/THUMB] Button
GY-HM150U.book Page 18 Monday, September 5, 2011 1:48 AM

JVC GY-HM150U Specifications

General

Sensor type	CCD
Number of CCDs	3
Total megapixels	- MP
Optical sensor size	1/4 \
Digital zoom	- x
Optical zoom	10 x
Image stabilizer	Yes
Focal length range	3.7 - 37 mm
Interchangeable lens	-
Image stabilizer type	Optical Image Stabilization (OIS)
Maximum aperture number	2.8
Minimum aperture number	1.8
Maximum focal length (35mm film equiv)	390 mm
Minimum focal length (35mm film equiv)	39 mm
Memory slots	2
Camcorder media type	Memory card
Disc types supported	No
Compatible memory cards	SDHC, SDXC
Internal storage capacity	- GB
Camera shutter speed	0.0001 - 0.27 s
Display diagonal	2.7 \
Display aspect ratio	16:9
Display resolution (numeric)	230000 pixels
Viewfinder type	Electronic
Viewfinder resolution	260000 pixels
Viewfinder screen size	0.24 \
Camcorder type	Handheld camcorder
Product color	Black
Video resolutions	720 x 480, 1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Supported video modes	1080i, 480i, 480p, 720p
Video formats supported	AVI, MOV, MP4, MPEG2
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Bitrate at maximum video resolution	35 Mbit/s
Audio formats supported	LPCM
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	0
Component video (YPbPr/YCbCr) out	1
Battery voltage	7.2 V
Charging source	AC
Battery capacity	- mAh
Battery life (max)	- h
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	30 - 80 %
Cables included	AV, Component
Power consumption	7.8 W

Weight and Dimensions

Depth	366 mm
Width	138 mm
Height	179 mm
Weight	1400 g
