JVC GY-HM150U User Manual

5
White Balance Adjustment Feature
Enables white balance to be adjusted automatically or
manually.
Built-in Color Bars (Multi-format Color
Bars)
Slow Shutter
Makes it possible to brightly shoot video of dark subjects with
little motion by accumulating the images.
Two Audio Input Terminals
This camera recorder comes with two XLR terminals, which
can be used as audio input terminals for the built-in or
external microphone.
Three Video Output Terminals
This camera recorder comes with an HDMI terminal, a
component terminal, and an A/V OUT (video/audio output)
terminal, which support a wide variety of TV monitor types.
Supports Wired Remote Control
Connection to PCs via USB Port
Files stored on an SDHC/SDXC card can be retrieved to a
PC.
Saving and Loading of Setting Files
The current menu and camera recorder settings can be
saved to an SDHC/SDXC card (Up to eight files). In addition,
settings files stored on the SDHC/SDXC card can also be
loaded onto the camera recorder according to the shooting
scene to reproduce the most suitable settings.
Application Software Provided
The [JVC ProHD Clip Manager] application software is
provided for you to copy recorded clips to Windows or
Macintosh PCs and for checking the video images, etc.
(For MP4 file format)
The CD-ROM provided with this camera recorder
comes with [JVC ProHD Clip Manager] and other
application software as well as their user guides.
* For details, refer to the user guides for each application
software.
GY-HM150U.book Page 5 Monday, September 5, 2011 1:48 AM

JVC GY-HM150U Specifications

General

Sensor type	CCD
Number of CCDs	3
Total megapixels	- MP
Optical sensor size	1/4 \
Digital zoom	- x
Optical zoom	10 x
Image stabilizer	Yes
Focal length range	3.7 - 37 mm
Interchangeable lens	-
Image stabilizer type	Optical Image Stabilization (OIS)
Maximum aperture number	2.8
Minimum aperture number	1.8
Maximum focal length (35mm film equiv)	390 mm
Minimum focal length (35mm film equiv)	39 mm
Memory slots	2
Camcorder media type	Memory card
Disc types supported	No
Compatible memory cards	SDHC, SDXC
Internal storage capacity	- GB
Camera shutter speed	0.0001 - 0.27 s
Display diagonal	2.7 \
Display aspect ratio	16:9
Display resolution (numeric)	230000 pixels
Viewfinder type	Electronic
Viewfinder resolution	260000 pixels
Viewfinder screen size	0.24 \
Camcorder type	Handheld camcorder
Product color	Black
Video resolutions	720 x 480, 1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Supported video modes	1080i, 480i, 480p, 720p
Video formats supported	AVI, MOV, MP4, MPEG2
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Bitrate at maximum video resolution	35 Mbit/s
Audio formats supported	LPCM
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	0
Component video (YPbPr/YCbCr) out	1
Battery voltage	7.2 V
Charging source	AC
Battery capacity	- mAh
Battery life (max)	- h
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	30 - 80 %
Cables included	AV, Component
Power consumption	7.8 W

Weight and Dimensions

Depth	366 mm
Width	138 mm
Height	179 mm
Weight	1400 g
