Status Screen
STATUS 0 Screen
The STATUS 0 screen is not displayed in the AUX mode. (U model)
Status Screen in Camera
Mode
STBY
MAX 123%
MIN 45%
SKIN AREA
S.DTL
B -3
A<3200K>
F5.6 AE+1 9dB 1/10000
30/24 fps
2
0
mi
n
DD
RE
S
1
m
in
1min
B
B
A
A
A
M
L
K
J
I
H
G
F
EDBC
A
Appears only when a warning is displayed. (A Page 104)
Appears only when connected to an external device.
Item Description
A Media Status
---- : No card found in the selected slot *
STBY : Recording standby (recording pause)
REC : Recording
REVIEW : Clip Review (A Page 56)
STBYP : Pre Rec recording standby (A Page 58)
RECP : Pre Rec recording (A Page 58)
STBYC : Clip Continuous recording standby
(A Page 59)
RECC : Clip Continuous recording (A Page 59)
STBYC (displayed in yellow)
: Clip Continuous recording pause
(A Page 59)
STOP : Unable to record to the card in the slot
POFF : Power OFF
* When [Tally System] in the [Others] menu is set to AStudioB, A----B is not displayed even when a
card is not inserted into the slot. ( A Page 94)
B Iris Status Mark
Indicates whether the brightness of the image is appropriate.
J : Iris set higher than normal
R : Iris set to normal
K : Iris set lower than normal
C Iris F-Number
Displays F-number of the lens iris.
This is not displayed for some lens types, and when the lens cable is disconnected.
(OPEN, F2, F2.8, F4, F5.6, F8, F11, F16, CLOSE)
Memo :
● You can specify the type of display and whether to display the information using [F.No/Iris Indicator] of
[Status Display] in the [LCD/VF] menu. ( A Page 90)
D AE Level
Appears when the AE function is activated and [AE LEVEL] in the [Camera Function] menu is set to a
value other than ANormalB. (A Page 78)
(AE-3, AE-2, AE-1, AE+1, AE+2, AE+3)
E Gain
Displays the gain value when it is not A0dBB.
(3dB, 6dB, 9dB, 12dB, 15dB, 18dB, ALC)
F Shutter
Displays the current shutter speed when [Shutter] in the [Camera Function] menu is set to [Step]/
[Variable] and the shutter is ON. (A Page 78)
EEI : Displayed when [Shutter] is set to AEEIB (auto adjustment mode).
FAS : Displayed when shutter or gain is set to the auto adjustment mode.
Memo :
● The variable range of the shutter speed varies according to the video format settings. ( A Page 41)
G White Balance Mode
Displays the current white balance mode.
A<**00K>, B<**00K>, P<**00K> ( A **00 B indicates color temperature)
FAW : When the Fulltime Auto White balance mode is ON
MANU : Manual White Balance mode (only during control using the Remote Control Unit)
