JVC PD-35B50BJ - Voltage Chart

No. YA098
No. YA098 2-85 2-86
PIN NO. VOLTAGE(V) PIN NO. VOLTAGE(V) PIN NO. VOLTAGE(V) PIN NO. VOLTAGE(V) PIN NO. VOLTAGE(V) PIN NO. VOLTAGE(V) PIN NO. VOLTAGE(V) PIN NO. VOLTAGE(V) PIN NO. VOLTAGE(V)
< RECEIVER PWB >
[P.2-7 – P.2-8]
VOLTAGE CHART
< ANALOG SIGNAL PWB >
[P.2-9 – P.2-10]
[P.2-13 – P.2-14]
< AV JACK PWB >
[P.2-19 – P.2-20]
< DIGITAL SIGNAL PWB >
[P.2-21 - P.2-22]
IC3001
1 3.5
2 5.4
30
4 4.8
5 4.8
60
7 4.7
80
9 3.7
10 0
11 2.8
12 0
13 2.9
14 0
15 4.7
16 0
17 3.5
18 4.1
19 4.9
20 4.9
21 2.0
22 2.3
IC3501
1 4.8
2 4.8
3 1.5
40
5 2.2
6 2.2
7 1.7
80
90
10 2.4
11 4.8
12 4.8
13 4.8
14 0.6
15 0.5
16 0.5
17 0.5
18 0.5
19 4.8
20 0.1
21 0.5
22 4.8
23 0
24 0
25 0
26 0
27 0
28 0
29 0
30 3.8
31 3.8
32 0
33 8.0
34 7.0
35 0
36 3.7
37 3.7
38 3.7
39 0
40 3.7
41 3.7
42 2.6
43 3.8
44 0
IC3502
1 4.4
2 4.5
3 4.4
40
5 4.5
6 4.4
7 4.4
8 8.9
IC3504
1 8.9
20
3 8.0
Q3001
E 2.2
C 9.0
B 2.8
Q3502
E0
C 8.9
B0
Q3503
E0
C 4.8
B0
IC501
1 4.0
2 4.5
3 4.0
4 4.5
5 4.4
6 0.1
7 4.9
8 4.1
9 4.4
10 4.1
11 4.4
12 4.4
13 6.8
14 0
15 4.3
16 4.4
17 4.3
18 4.4
19 4.4
20 6.7
21 0
22 3.8
23 4.4
24 4.0
25 4.5
26 4.4
27 6.7
28 0
29 4.4
30 4.0
31 4.5
32 9.0
33 4.8
34 4.8
35 0
36 0
37 4.4
38 4.4
39 3.7
40 4.4
41 4.4
42 9.0
43 4.5
44 4.3
45 4.5
46 3.7
47 0
48 0
49 4.9
50 4.4
51 0
52 4.5
53 4.4
54 4.5
55 3.7
56 4.0
57 0
58 4.2
59 4.4
60 4.0
61 4.4
62 4.4
63 4.4
64 4.4
IC502
1 3.1
2 3.2
30
4 2.7
50
6 9.0
IC503
1 3.0
2 3.0
3 9.0
4 2.7
50
6 9.0
Q501
E0
C 6.7
B0
Q502
E0
C 6.7
B0
Q503
E0
C 6.8
B0
Q504
E0
C 6.8
B0
Q505
E0
C 6.8
B0
Q506
E0
C 6.8
B0
Q507
E 1.2
C0
B 0.6
Q508
E 2.8
C0
B 2.2
Q509
E0
C0
B 0.4
Q511
E0
C 6.5
B0
Q512
E 4.8
C 4.9
B 5.4
Q513
E 4.7
C 4.9
B 5.4
[P.2-11 – P.2-12]
PIN NO. VOLTAGE(V)
IC711
10
2 2.4
3 4.6
4 0.3
5 0.3
6 4.6
7 0.3
80
9 2.4
10 0
11 5.0
12 4.9
13 0
14 4.9
15 4.8
16 4.9
IC801
1 2.3
2 2.0
3 1.5
4 0.1
5 2.2
6 4.8
7 2.4
80
9 0.3
10 0.8
11 2.3
12 4.8
13 4.8
14 4.8
15 0
16 0
17 0
18 0
19 0
20 2.3
21 1.5
22 1.7
23 1.7
24 0
25 2.4
26 2.4
27 2.4
28 0
29 0
30 0
31 0
32 4.8
33 2.4
34 2.4
35 2.4
36 0.5
37 4.8
38 3.8
39 1.6
40 3.2
41 2.2
42 4.4
43 1.6
44 2.2
45 4.8
46 1.8
47 3.6
48 1.7
IC802
1 1.3
2 3.0
3 4.8
4 2.4
50
6 1.8
7 2.2
80
90
10 0
11 4.7
12 0
13 4.8
14 0
15 4.9
16 4.8
17 0
18 0
19 2.4
20 4.8
21 0
22 2.6
23 2.6
24 3.3
25 3.3
26 0
27 3.5
28 1.6
Q402
S 3.0
D 3.1
G 4.9
Q403
S 2.9
D 3.1
G 4.8
Q404
S 3.0
D 3.2
G 4.8
Q405
S 3.0
D 3.2
G 4.9
Q801
E 2.7
C0
B 2.1
Q802
E 2.6
C0
B 2.0
Q810
E 2.0
C0
B 1.4
Q851
E 1.6
C0
B 1.0
Q853
E 2.0
C 8.9
B 2.6
Q854
E 2.6
C 8.9
B 3.3
Q855
E 1.9
C0
B 1.3
Q858
E 2.9
C9
B 3.5
Q859
E 3.5
C0
B 2.9
Q862
E 0.9
C 3.9
B 1.5
Q863
E 3.2
C 4.8
B 3.9
IC201
1 0.3
2 0.1
30
40
50
60
7 6.2
80
9 4.8
10 0
11 8.8
12 1.3
13 0
14 0
15 0
16 0
17 0
18 0
19 0.5
20 0
21 4.9
22 4.9
23 0
24 2.1
25 1.2
26 2.1
27 0
28 2.4
29 0.1
30 0.5
IC202
1 0.5
2 0.5
30
4 0.2
50
IC301
1 4.8
2 4.9
3 4.9
40
5 4.7
60
7 4.6
8 4.7
9 4.7
10 0.4
11 4.5
12 4.4
13 0
14 4.6
15 0
16 4.7
17 4.7
18 4.7
19 0
20 4.5
21 4.4
22 0
23 4.4
24 4.5
25 0
26 4.4
27 4.4
28 0
29 0
30 4.4
31 9.0
32 4.5
33 4.5
34 0
35 4.5
36 4.5
37 0
38 4.5
39 4.5
40 4.5
41 4.5
42 0
43 4.5
44 4.5
45 0
46 4.5
47 8.9
48 4.7
49 0
50 4.7
51 0
52 4.7
53 0
54 4.4
55 4.4
56 0
57 4.6
58 0
59 4.7
60 0
61 4.7
62 0.4
63 4.4
64 4.5
65 0
66 4.6
67 4.7
68 4.6
69 0
70 4.4
71 4.3
72 0
73 4.8
74 4.7
75 4.6
76 4.6
77 0
78 4.4
79 4.5
80 0
Q307
E 2.9
C0
B 2.3
[P.2-15 – P.2-16]
PIN NO. VOLTAGE(V)
IC604
1 4.6
2 4.4
3 4.2
40
5 4.3
6 4.3
7 4.5
8 9.0
IC605
1 1.1
2 1.1
3 1.1
40
5 2.5
60
70
8 1.2
90
10 1.3
11 1.2
12 1.2
13 2.5
14 2.5
15 1.1
16 1.1
IC606
1 2.5
20
30
4 1.2
5 9.0
60
7 9.0
IC607
10
20
30
40
50
6 3.1
70
80
9 2.5
10 1.1
11 1.0
12 0
13 2.5
14 2.4
15 0
16 0
17 2.5
18 2.5
19 0
20 0
21 2.5
22 2.5
23 0
24 0
25 0.3
26 0
27 0
28 0
29 0
30 1.2
31 1.3
32 1.2
Q602
E0
C 2.5
B0
Q605
E0
C 2.5
B0
Q606
E 3.7
C 9.0
B 4.3
Q607
E 3.8
C 9.0
B 4.4
[P.2-17 – P.2-18]
PIN NO. VOLTAGE(V)
IC902
1 4.7
20
3 3.3
Q901
E 9.7
C 9.0
B 9.0
Q902
E 5.6
C 4.9
B 4.8
Q2001
E0
C0
B -0.2
Q2002
E0
C -0.2
B0
Q2003
E0
C0
B -0.2
Q2004
E0
C0
B -0.2
Q2005
E0
C -0.2
B0
Q2006
E0
C0
B -0.2
Q2007
E0
C0
B -0.1
Q2008
E0
C -0.2
B0
Q2009
E0
C0
B -0.2
Q2010
E0
C0
B -0.2
Q2011
E0
C -0.2
B0
IC1502
1 4.4
20
3 3.7
40
50
69
7 3.7
80
[P.2-23 – P.2-24]
PIN NO. VOLTAGE(V)
IC0401
1 3.2
2 0.2
30
4 3.1
5 3.3
Q0101
E 3.8
C 7.7
B 4.5
Q0102
E 8.5
C 4.6
B 7.7
Q0104
E 5.3
C0
B 4.6
Q0107
E 1.5
C0
B 0.9
Q0108
E 0.8
C 9.0
B 1.5
Q0109
1 1.4
2 0.1
3 1.4
4 1.5
5 0.1
6 1.5
Q0110
10
2 0.6
3 0.6
4 0.1
5 0.6
6 0.1
Q0201
E 3.7
C 7.7
B 4.5
Q0202
E 8.5
C 4.9
B 7.7
Q0203
E0
C 1.9
B0
Q0204
E 5.6
C0
B 4.9
Q0207
E 2.5
C0
B 1.9
Q0208
E 1.8
C 9.0
B 2.4
Q0209
1 2.4
2 0.2
3 2.4
4 2.4
5 0.2
6 2.5
Q0210
10
2 0.6
3 0.6
4 0.1
5 0.6
6 0.2
Q0301
E 3.7
C 7.7
B 4.5
PIN NO. VOLTAGE(V)
PIN NO. VOLTAGE(V)
PIN NO. VOLTAGE(V)
PIN NO. VOLTAGE(V)
PIN NO. VOLTAGE(V)
PIN NO. VOLTAGE(V)
PIN NO. VOLTAGE(V)
PIN NO. VOLTAGE(V)
PIN NO. VOLTAGE(V)
[P.2-39 – P.2-40]
Q0302
E 8.5
C 4.9
B 7.7
Q0303
E0
C 1.9
B0
Q0304
E 5.7
C0
B 5.0
Q0307
E 2.5
C0
B 1.9
Q0308
E 1.8
C 9.0
B 2.4
Q0309
1 2.4
2 0.1
3 2.4
4 2.5
5 0.1
6 2.5
Q0310
10
2 0.6
3 0.6
4 0.1
5 0.6
6 0.1
[P.2-25 – P.2-26]
PIN NO. VOLTAGE(V)
IC1001
1 2.5
2 1.3
3 1.3
40
5 3.3
6 1.7
7 1.6
80
90
10 1.5
11 0
12 0
13 0
14 0
15 0
16 0
17 1.5
18 0
19 0
20 0
21 1.5
22 0
23 0
24 3.3
25 0
26 0
27 0
28 0
29 0
30 3.3
31 3.3
32 3.3
33 0
34 0
35 0
36 1.4
37 0
38 0
39 0
40 0
41 0
42 3.3
43 0.9
44 0.9
45 0
46 1.0
47 1.8
48 0.9
49 1.0
50 0
51 1.6
52 0
53 2.5
54 1.3
55 1.3
56 0
57 0
58 1.5
59 1.5
60 0
61 0
62 0
63 0.9
64 3.3
65 1.0
66 1.0
67 0
68 0.9
69 0.9
70 1.5
71 0.9
72 0.9
73 0
74 2.3
75 0.2
76 0
77 1.7
78 1.5
79 0
80 1
81 0.9
82 1.7
83 1.2
84 0
85 1.1
86 2.4
87 0.7
88 0.8
89 1.7
90 1.2
91 2.4
92 1.2
93 0
94 1.2
95 0.7
96 2.8
97 1.9
98 0
99 1.1
100 1.5
Q1001
E0
C 3.3
B0
Q1003
E 1.2
C 2.4
B 1.9
Q1004
E 4.2
C0
B 3.8
Q1101
E 3.1
C 9.0
B 3.7
Q1103
E 1.8
C0
B 1.2
Q1201
E 3.7
C 9.0
B 4.4
Q1203
E 2.0
C0
B 1.3
Q1301
E 3.9
C 9.0
B 4.5
Q1303
E 2.5
C0
B 2.0
Q1401
E 3.9
C 9.0
B 4.5
Q1403
E 2.6
C0
B 2.0
[P.2-29 – P.2-30]
PIN NO. VOLTAGE(V)
IC3403
10
2 3.3
30
4 3.3
IC3501
1 1.2
2 2.5
3 1.2
4 1.2
50
6 1.2
7 1.2
8 2.4
9 1.2
10 1.2
11 0
12 1.2
13 1.2
14 2.5
15 2.5
16 0
17 1.2
18 1.2
19 0
20 1.2
21 1.2
22 2.5
23 0.4
24 0.4
25 1.7
26 1.7
27 1.7
28 0
29 0.7
30 0.7
31 0.7
32 0.7
33 0.7
34 0.7
35 2.5
36 0.7
37 0
38 0
39 0
40 0
41 0
42 0
43 0
44 0
45 0.7
46 0
47 0.7
48 0.7
49 0.7
50 0.6
51 0.7
52 0
53 1.8
54 1.3
55 1.1
56 0.2
57 0.4
58 1.2
59 2.5
60 1.2
61 1.2
62 0
63 1.2
64 1.2
65 2.4
66 0
67 2.5
68 1.2
69 1.2
70 0
71 1.2
72 1.2
73 2.5
74 1.2
75 1.2
76 0
77 0
78 1.2
79 2.5
80 1.2
81 1.2
82 0
83 1.2
84 1.2
85 0
86 2.5
87 0
88 0
89 0
90 0
91 0
92 0
93 0
94 0
95 0
96 0
97 1.1
98 0
99 0
100 1.2
IC3502
1 1.2
2 2.5
3 1.2
4 1.2
50
60
70
8 2.5
9 1.2
10 0
11 0.1
12 0
13 1.2
14 2.5
15 2.5
16 0
17 0
18 1.2
19 0
20 1.2
21 1.2
22 2.4
23 0
24 0.1
25 0
26 1.7
27 0
28 0.1
29 0.7
30 0.7
31 0.7
32 0.5
33 0.6
34 0.7
35 2.5
36 0
37 0
38 0
39 0
40 0
41 0
42 0
43 0
44 0
45 0
46 0
47 0.7
48 0
49 0.7
50 0.7
51 0.7
52 0
53 1.7
54 0
55 1.2
56 0.3
57 0.3
58 1.2
59 0
60 1.2
61 1.2
62 0
63 0.2
64 0
65 2.5
66 0
67 2.5
68 1.2
69 1.2
70 0
71 0
72 0.1
73 0.1
74 1.2
75 0
76 0
77 1.2
78 1.2
79 0
80 1.2
81 0.7
82 0
83 0
84 1.2
85 0
86 2.5
87 0
88 0
IC7001
1 3.3
20
3 3.3
40
50
60
70
8 3.3
9 3.3
10 0
11 3.3
12 3.3
13 0
14 3.3
15 3.3
16 3.3
17 3.3
18 0
19 0
20 3.3
21 3.3
22 3.3
23 1.6
24 1.4
25 3.3
26 0
27 0
28 0
29 0
30 0
31 0
32 3.3
33 0
34 3.3
35 0.5
36 3.3
37 0
38 0
39 0.3
40 0.2
41 0
42 0
43 0
44 0
45 0
46 0.4
47 0.4
48 3.3
49 0
50 2.6
51 3.3
52 3.3
53 0.5
54 3.3
55 3.9
56 3.3
57 3.3
58 3.3
59 3.3
60 3.3
61 0
62 3.3
63 1.7
64 0
65 0
66 3.3
67 3.0
68 3.3
69 3.3
70 3.3
71 3.3
72 0
73 3.3
74 3.3
75 3.2
76 3.3
77 3.6
78 0
79 3.2
80 0
81 3.3
82 3.3
83 0
84 3.3
85 3.3
86 3.3
87 3.3
88 0
89 0
90 3.3
91 0
92 0
93 3.3
94 0
95 3.3
96 3.2
97 0
98 0
99 3.3
100 3.3
IC7002
10
20
30
40
5 3.0
6 3.1
70
8 3.3
IC7401
1 3.3
2 3.3
30
40
Q7201
E 4.8
C 0.3
B 4.2
Q7202
E 4.0
C 4.3
B 2.3
Q7203
E 4.0
C 4.8
B 4.4
Q7204
E0
C 4.7
B0
Q7205
E0
C0
B0
Q7206
E0
C 2.5
B 0.6
Q7207
E 3.2
C 3.2
B0
[P.2-41 – P.2-42]
PIN NO. VOLTAGE(V)
IC7501
1 3.3
2 0.1
30
4 3.3
5 0.1
60
70
80
90
10 0
11 0.2
12 3.3
13 0
14 3.2
15 0
16 0
17 0
18 0
19 0
20 0
21 2.4
22 0
23 0
24 2.7
25 0
26 0.5
27 2.4
28 0
29 0
30 0.7
31 0
32 3.3
33 0.5
34 0.5
35 1.6
36 1.1
37 0
38 0.6
39 2.9
40 2.6
41 0
42 3.3
43 1.2
44 2.6
45 3.2
46 3.2
47 3.2
48 0
49 0
50 3.2
51 1.0
52 0
53 3.3
54 1.0
55 0.1
56 1.8
57 0.2
58 1.4
59 1.6
60 0
61 3.2
62 0.2
63 0.1
64 1.7
65 2.0
66 1.1
67 0.8
68 0
69 3.2
70 0.6
71 0.9
72 1.6
73 3.1
74 3.1
75 3.0
76 3.6
77 1.6
78 0
79 0
80 0
81 0
82 0
83 3.2
84 0
85 3.2
86 0
87 2.5
88 0
89 3.0
90 0
91 3.2
92 0
93 0
94 0
95 0
96 0
97 0
98 3.3
99 3.1
100 0
101 3.2
102 3.3
103 3.3
104 0
105 0
106 3.3
107 0
108 0.5
109 0.4
110 0
111 2.4
112 0.2
113 0.2
114 0.3
115 0
116 2.4
117 0
118 0
119 2.5
120 0
121 0.7
122 0
123 2.4
124 2.4
125 2.4
126 2.9
127 0.8
128 0
IC7502
1 3.1
2 3.2
30
40
IC7503
1 3.2
20
3 3.2
4 1.5
10 1.0
11 0.5
12 0.5
13 0
14 0
15 0.7
16 0.6
17 0
18 1.0
19 0.8
20 0.6
21 0
22 0.7
23 0.6
24 0.1
25 1.7
26 0.1
27 3.3
28 0
29 0
30 3.3
31 0.6
32 3.3
33 0
34 3.3
35 0
36 0
37 1.2
38 1.3
39 1.2
40 1.2
41 1.2
42 1.3
43 0
44 3.3
45 0
46 1.4
47 1.4
48 0
49 0
50 0
51 0.7
52 0.7
53 0
54 0.6
55 0.7
56 0.6
CN0LV2
10
20
3 1.3
4 1.2
50
60
7 1.3
8 1.0
9 0.1
10 0
11 1.3
12 1.2
13 0
14 0
15 0
16 1.3
17 0
18 0
19 1.3
20 0
21 0
22 3.2
23 0
24 0
25 0
26 0
27 3.0
28 0
29 3.0
30 0
31 0
[P.2-37 – P.2-38]
PIN NO. VOLTAGE(V)
IC7602
10
20
30
40
5 3.3
6 3.2
70
8 3.3
89 0
90 0
91 0
92 0
93 0
94 1.2
95 2.5
96 2.5
97 1.2
98 1.2
99 0
100 0
IC3503
10
2 2.5
3 1.2
4 1.2
5 2.5
6 2.5
7 2.5
8 1.2
Q3001
E 2.2
C 3.3
B 2.9
Q3002
E 2.9
C0
B 2.1
Q3003
E 0.6
C 3.3
B 1.3
Q3004
E 1.4
C0
B 0.7
[P.2-31 – P.2-32]
PIN NO. VOLTAGE(V)
IC4003
10
20
30
40
50
60
70
8 0.1
9 0.1
10 0
11 0
12 0
13 0
14 0
15 0
16 0
17 0
18 0
19 0
20 0
21 0.5
22 0.5
23 0.5
24 0
25 0.5
26 0.5
27 0.5
28 0.5
29 0.5
30 3.3
31 0
32 0
IC4004
10
20
30
40
5 3.3
6 3.3
70
8 3.3
[P.2-33 – P.2-34]
PIN NO. VOLTAGE(V)
IC6502
1 3.3
20
3 0.6
4 0.4
50
6 0.5
7 0.5
8 1.1
9 3.3
