3-6(No.YA098)
EXPLODED VIEW PARTS LIST - 2
Ref.No. Part No. Part Name Description Local
20 QYSBSGG3008ZA TAP SCREW M3 x 8mm
21 QYSDSF3008MA TAP SCREW M3 x 8mm(x6)
22 CE42112-002 PALJ CONNECTOR
23 CHGY0017-0B-UK E-COAXIAL ASS'Y
24 LC21552-001A-0K TERMINAL BOARD
25 QYSBSG3012MA TAP SCREW M3 x 12mm
26 QYSBSG3008MA TAP SCREW M3 x 8mm
27 LC21553-001C AC INLET PANEL
28 QYSBSG3008MA TAP SCREW M3 x 8mm(x3)
29 LC41903-001A CONNECT COVER (x2)
30 LC21550-001B-0K DIGITAL TERMINAL COVER
31 QQR0491-001 FERRITE CORE GRAY
32 QUQ105-5034AE FFC WIRE
33 QUQ105-3004AA FFC WIRE
34 QUQ105-5004AA FFC WIRE
35 QUQ105-5007AE FFC WIRE
36 QUQ105-5007AE FFC WIRE
37 QUQ105-4004AA FFC WIRE
38 QUQ105-3022AH FFC WIRE
40 SFP-6001A-U2 AUDIO PWB
41 SFP0J201A-U2 AV JACK PWB
42 SFP-7201A-U2 INTERFACE PWB
43 SFP-9203A-U2 REGULATOR PWB
44 SFP-9204A-U2 LINE FILTER PWB
45 SFP0F203A-U2 RECEIVER PWB
46 SFP0A201A-U2 ANALOG SIGNAL PWB
47 SFP0D201A-U2 DIGITAL SIGNAL PWB
