JVC PD-35B50BJ - Receiver P.w. Board Assy (Sfp0 F201 A-U2)

(No.YA098)3-27
RECEIVER P.W. BOARD ASS'Y (SFP0F201A-U2)
L3010 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
L3012 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
L3501 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
L4001 NQR0413-003X FERRITE BEADS
L4002 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
L4003 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
L6501 NQR0351-001X FERRITE BEADS
L6508 NRZ0034-0R0W NET RESISTOR 0 Ω 1/32W J
L6509 NRZ0034-0R0W NET RESISTOR 0 Ω 1/32W J
L6510 NRZ0034-0R0W NET RESISTOR 0 Ω 1/32W J
L7001 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
L7002 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
L7003 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
L7004 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
L7005 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
L7006 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
L7501 NQL092K-4R7X COIL 4.7uH K
L7502 NQL092K-4R7X COIL 4.7uH K
L7503 NQL092K-4R7X COIL 4.7uH K
L7504 NQL092K-4R7X COIL 4.7uH K
L7505 NQL092K-4R7X COIL 4.7uH K
L7506 NQL914M-4R7X COIL 4.7uH M
L7507 NQL092K-4R7X COIL 4.7uH K
L7508 NQL092K-4R7X COIL 4.7uH K
L7509 NQL092K-4R7X COIL 4.7uH K
L7510 NQL092K-4R7X COIL 4.7uH K
L7511 NQL092K-4R7X COIL 4.7uH K
L7512 NQL914M-4R7X COIL 4.7uH M
L7513 NQL914M-4R7X COIL 4.7uH M
L7514 NQL092K-4R7X COIL 4.7uH K
L9001 NQL71EM-150X COIL 15uH M
L9101 NQL71EM-150X COIL 15uH M
L9201 NQL71EM-150X COIL 15uH M
K1001 NQR0489-002X FERRITE BEADS
K1002 NQR0489-002X FERRITE BEADS
K1003 NQR0489-002X FERRITE BEADS
K1004 NQR0489-002X FERRITE BEADS
K3003 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K3006 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K6001 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K6002 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K6003 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K6004 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K6005 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K6006 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K6007 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K6008 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K6009 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K6010 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K6011 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K6012 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K6013 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K6014 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K6015 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K6016 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K6017 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K6018 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K6019 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K6020 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K6021 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K7002 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K7501 NRSA63J-390X MG RESISTOR 39 Ω 1/16W J
K7502 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K7503 NQR0389-003X FERRITE BEADS
LC0102 NQR0483-005X EMI FILTER
LC0518 NQR0416-001X EMI FILTER 240pF 16V M
LC0519 NQR0416-001X EMI FILTER 240pF 16V M
LC7501 NQR0313-007X EMI FILTER 1000pF 50V M
LC7502 NQR0431-001X EMI FILTER 0.22uF 50V Z
SL7001 NAX0613-001X C RESONATOR
X1001 NAX0642-001X CRYSTAL
X3001 NAX0635-001X CXO
X3002 NAX0667-001X CXO
X4001 NAX0669-001X C RESONATOR
X7501 NAX0618-001X CRYSTAL
 Ref No. Part No. Part Name Description Local
IC3001 QAU0374-001 TUNER 80pin
IC3501 MSP3415DQGB3GHX IC
 Ref No. Part No. Part Name Description Local
IC3502 HA17558AF-X IC
IC3504 BA80BC0FP-X IC
Q3001 2SC3928A/QR/-X TRANSISTOR
Q3502 2SC3928A/QR/-X TRANSISTOR
Q3503 UN2213-X DIGI TRANSISTOR
D3501 MA8100/M/-X Z DIODE
C3001 NCB31HK-222X C CAPACITOR 2200pF 50V K
C3002 NEH71HM-106X E CAPACITOR 10uF 50V M
C3003 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C3004 NEH71AM-107X E CAPACITOR 100uF 10V M
C3005 NCB31HK-333X C CAPACITOR 0.033uF 50V K
C3007 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C3008 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C3009 NEH71HM-106X E CAPACITOR 10uF 50V M
C3010 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C3011 NEH71HM-106X E CAPACITOR 10uF 50V M
C3012 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C3014 NEH71HM-106X E CAPACITOR 10uF 50V M
C3015 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C3501 NCB11AK-106X C CAPACITOR 10uF 10V K
C3502 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C3503 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C3504 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C3505 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
C3511 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C3512 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C3513 NDC31HJ-2R0X C CAPACITOR 2pF 50V J
C3514 NDC31HJ-2R0X C CAPACITOR 2pF 50V J
C3515 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C3516 NEH71AM-107X E CAPACITOR 100uF 10V M
C3517 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C3518 NCB31HK-222X C CAPACITOR 2200pF 50V K
C3519 NCB31CK-105X C CAPACITOR 1uF 16V K
C3520 NDC31HJ-102X C CAPACITOR 1000pF 50V J
C3521 NCB31CK-105X C CAPACITOR 1uF 16V K
C3522 NDC31HJ-102X C CAPACITOR 1000pF 50V J
C3523 NDC31HJ-102X C CAPACITOR 1000pF 50V J
C3524 NDC31HJ-102X C CAPACITOR 1000pF 50V J
C3525 NEH71CM-106X E CAPACITOR 10uF 16V M
C3526 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C3527 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C3528 NEH71AM-107X E CAPACITOR 100uF 10V M
C3529 NEH71CM-106X E CAPACITOR 10uF 16V M
C3530 NCB11AK-106X C CAPACITOR 10uF 10V K
C3531 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C3532 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C3533 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C3534 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C3535 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C3536 NCB11AK-106X C CAPACITOR 10uF 10V K
C3537 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C3540 NCB31HK-183X C CAPACITOR 0.018uF 50V K
C3541 NCB31CK-683X C CAPACITOR 0.068uF 16V K
C3542 NEH71CM-476X E CAPACITOR 47uF 16V M
C3543 NEH71CM-476X E CAPACITOR 47uF 16V M
C3544 NCB31AK-105X C CAPACITOR 1uF 10V K
C3546 NCB31AK-105X C CAPACITOR 1uF 10V K
C3548 NCB11AK-106X C CAPACITOR 10uF 10V K
R3002 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R3003 NRSA63J-154X MG RESISTOR 150k
Ω 1/16W J
R3006 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R3007 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R3008 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R3009 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R3010 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R3011 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R3014 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R3015 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R3016 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R3017 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R3018 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R3111 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R3112 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R3501 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R3502 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R3508 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R3511 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R3512 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R3513 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R3514 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R3515 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R3516 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R3517 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
 Ref No. Part No. Part Name Description Local
