JVC PD-35B50BJ - Sub Power P.w. Board Assy (Sfp-9202 A-U2)

(No.YA098)3-17
SUB POWER P.W. BOARD ASS'Y (SFP-9202A-U2)
R9425 NRSA63D-222X MG RESISTOR 2.2k Ω 1/16W D
R9426 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R9435 QRE121J-124Y C RESISTOR 120k Ω 1/2W J
R9436 NRSA63J-563X MG RESISTOR 56k Ω 1/16W J
R9450 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R9451 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R9452 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R9453 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R9454 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R9455 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R9456 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R9457 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R9601 QRX01GJ-1R8 MF RESISTOR 1.8 Ω 1W J
R9603 QRK126J-681X UNF C RESISTOR 680 Ω 1/2W J
 R9604 QRZ9017-100 FUSI RESISTOR 10 Ω 1/4W J
R9605 QRE121J-222Y C RESISTOR 2.2k Ω 1/2W J
R9606 QRE121J-183Y C RESISTOR 18k Ω 1/2W J
R9607 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R9608 NRS12BJ-823W MG RESISTOR 82k Ω 1/2W J
R9609 QRK126J-562X UNF C RESISTOR 5.6k Ω 1/2W J
R9610 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R9611 QRX01GJ-1R0 MF RESISTOR 1 Ω 1W J
R9613 QRK126J-681X UNF C RESISTOR 680 Ω 1/2W J
 R9614 QRZ9017-100 FUSI RESISTOR 10 Ω 1/4W J
R9615 QRE121J-222Y C RESISTOR 2.2k Ω 1/2W J
R9616 NRSA63J-562X MG RESISTOR 5.6k
Ω 1/16W J
R9617 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R9618 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R9619 QRK126J-562X UNF C RESISTOR 5.6k Ω 1/2W J
R9621 QRX01GJ-1R0 MF RESISTOR 1 Ω 1W J
R9623 QRK126J-681X UNF C RESISTOR 680 Ω 1/2W J
 R9624 QRZ9017-100 FUSI RESISTOR 10 Ω 1/4W J
R9625 QRE121J-222Y C RESISTOR 2.2k Ω 1/2W J
R9626 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R9627 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R9628 QVP0087-202Z TRIM RESISTOR Vscan VR 2k Ω 0.3W N
R9629 QRK126J-562X UNF C RESISTOR 5.6k Ω 1/2W J
R9632 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R9635 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R9636 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R9637 NRS12BJ-683W MG RESISTOR 68k Ω 1/2W J
R9638 NRS12BJ-683W MG RESISTOR 68k Ω 1/2W J
R9639 NRSA63J-224X MG RESISTOR 220k Ω 1/16W J
R9640 QVP0087-102Z TRIM RESISTOR Vset VR 1k Ω 0.3W N
R9641 NRSA63J-123X MG RESISTOR 12k Ω 1/16W J
R9642 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R9643 NRS12BJ-683W MG RESISTOR 68k Ω 1/2W J
R9644 NRS12BJ-683W MG RESISTOR 68k Ω 1/2W J
R9645 NRSA63J-224X MG RESISTOR 220k Ω 1/16W J
R9646 QVP0087-102Z TRIM RESISTOR Ve VR 1k Ω 0.3W N
R9647 NRSA63J-123X MG RESISTOR 12k Ω 1/16W J
R9648 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
 R9649 QRZ9009-1R5 FUSI RESISTOR 1.5 Ω 1/2W J
 R9650 QRZ9009-1R5 FUSI RESISTOR 1.5 Ω 1/2W J
 R9651 QRZ9009-1R5 FUSI RESISTOR 1.5 Ω 1/2W J
L9001 QQL26AM-4R7Z CHOKE COIL 4.7uH M
L9002 QQR1440-001 CHOKE COIL
L9201 QQR1432-001 CHOKE COIL
L9401 QQLZ026-5R0 COIL 5uH
± 7%
L9631 QQR1432-001 CHOKE COIL
 T9201 QQS0248-001 SW TRANSF
 T9401 QQS0246-001 SW TRANSF
 T9402 QQS0252-001 SW TRANSF
 T9601 QQS0250-001 SW TRANSF
 T9602 QQS0251-001 SW TRANSF
 T9603 QQS0251-001 SW TRANSF
 CP9001 QMFZ043-5R0Z-J1 FUSE 5A AC250V
 CP9002 QMFZ052-2R0-E FUSE 2A AC250V
 CP9202 ICP-N70-T IC PROTECTOR 2.5A
 CP9601 QMFZ052-2R0-E FUSE 2A AC250V
 LF9001 QQR1281-002 LINE FILTER
 RY9001 QSK0118-001 RELAY
 RY9002 QSK0090-001 RELAY
TH9001 QAD0125-471 P THERMISTOR 110
C° 470 Ω 16V
Y9601 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
Y9602 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
LC41755-001A RADIATION SHEET
CE41666-002 RADIATION SHEET (x2)
 Ref No. Part No. Part Name Description Local
 Ref No. Part No. Part Name Description Local
IC9001 STR-W6765-F5 IC
IC9051 UTCTL431-T IC
Q9071 KTC3199/YG/-T TRANSISTOR
D9001 MTZJ33B-T2 Z DIODE
D9004 RGP10J-5025-T3 SI DIODE
D9005 1SS133-T2 SI DIODE
D9006 RGP10J-5025-T3 SI DIODE
D9008 SARS01-T2 SI DIODE
D9009 SARS01-T2 SI DIODE
D9011 1SS133-T2 SI DIODE
D9051 RU4YX-F1 SI DIODE
D9052 RU4YX-F1 SI DIODE
D9053 FMX-G12S SI DIODE
D9054 RGP10J-5025-T3 SI DIODE
D9055 RD33E/B1/-T2 Z DIODE
D9071 RU4YX-F1 SI DIODE
D9072 1SS133-T2 SI DIODE
D9073 MTZJ5.1A-T2 Z DIODE
 PC9001 PS2851AL1/QW/ PHOTO COUPLER
C9001 QEZ0674-476 E CAPACITOR 47uF 450V M
C9002 QFP32JK-332 PP CAPACITOR 3300pF 630V K
C9003 QCZ0340-471 C CAPACITOR 470pF 2kV K
C9004 QCS31HJ-471Z C CAPACITOR 470pF 50V J
C9006 QCB31HK-562Z C CAPACITOR 5600pF 50V K
C9008 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C9010 QEHR1HM-105Z E CAPACITOR 1uF 50V M
C9011 QEHR1HM-336Z E CAPACITOR 33uF 50V M
C9051 QECQ1EM-228 E CAPACITOR 2200uF 25V M
C9053 QECQ1EM-228 E CAPACITOR 2200uF 25V M
C9054 QECQ1EM-228 E CAPACITOR 2200uF 25V M
C9055 QEHR2AM-106Z E CAPACITOR 10uF 100V M
C9057 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C9060 QECQ1EM-228 E CAPACITOR 2200uF 25V M
C9072 QECQ1EM-228 E CAPACITOR 2200uF 25V M
C9073 QEHR1HM-105Z E CAPACITOR 1uF 50V M
C9074 QEHR1HM-105Z E CAPACITOR 1uF 50V M
 C9901 QCZ9079-102 C CAPACITOR 1000pF AC250V M
 C9902 QCZ9079-102 C CAPACITOR 1000pF AC250V M
R9001 QRK126J-101X UNF C RESISTOR 100 Ω 1/2W J
R9002 QRX01GJ-R39 MF RESISTOR 0.39 Ω 1W J
R9004 QRL039J-563 OMF RESISTOR 56k Ω 3W J
R9005 QRL039J-563 OMF RESISTOR 56k Ω 3W J
R9006 QRE121J-122Y C RESISTOR 1.2k Ω 1/2W J
R9008 QRE121J-564Y C RESISTOR 560k Ω 1/2W J
R9009 QRL039J-220 OMF RESISTOR 22 Ω 3W J
 R9010 QRZ9017-470 FUSI RESISTOR 47 Ω 1/4W J
R9011 QRE141J-332Y C RESISTOR 3.3k
Ω 1/4W J
R9012 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R9050 QRG01GJ-821 OMF RESISTOR 820
Ω 1W J
R9051 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R9053 QRE141J-123Y C RESISTOR 12k
Ω 1/4W J
R9055 QRA14CF-1802Y CMF RESISTOR 18k Ω 1/4W F
R9057 QRA14CF-3301Y CMF RESISTOR 3.3k Ω 1/4W F
R9058 QRE141J-223Y C RESISTOR 22k Ω 1/4W J
R9059 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R9060 QRL029J-152 OMF RESISTOR 1.5k Ω 2W J
R9071 QRG01GJ-821 OMF RESISTOR 820 Ω 1W J
R9072 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R9073 QRE141J-332Y C RESISTOR 3.3k
Ω 1/4W J
R9074 QRE141J-822Y C RESISTOR 8.2k
Ω 1/4W J
R9075 QRE141J-473Y C RESISTOR 47k
Ω 1/4W J
L9051 QQL26AK-220Z CHOKE COIL 22uH K
 T9001 QQS0279-001 SW TRANSF
 CP9001 QMFZ043-5R0Z-J1 FUSE 5A AC250V
 CP9051 ICP-N70-T IC PROTECTOR 2.5A
 CP9071 ICP-N70-T IC PROTECTOR 2.5A
 CP9072 ICP-N70-T IC PROTECTOR 2.5A
 CP9073 ICP-N50-Y IC PROTECTOR 2.0A
