JVC PD-35B50BJ - Front Control P.w. Board Assy (Sfp-8201 A-U2); Front Led P.w. Board Assy (Sfp-8201 A-U2); Temp. Sensor P.w. Board Assy (Sfp-8201 A-U2); Sub Power P.w. Board Assy (Sfp-9202 A-U2)

3-42(No.YA098)
FRONT CONTROL P.W. BOARD ASS'Y
(SFP-8201A-U2)
REFER TO PARTS LIST IN PAGE 3-14 FOR THIS P.W. BOARD.
FRONT LED P.W. BOARD ASS'Y (SFP-8201A-U2)
REFER TO PARTS LIST IN PAGE 3-15 FOR THIS P.W. BOARD.
TEMP. SENSOR P.W. BOARD ASS'Y (SFP-8201A-U2)
REFER TO PARTS LIST IN PAGE 3-15 FOR THIS P.W. BOARD.
SUB POWER P.W. BOARD ASS'Y (SFP-9202A-U2)
REFER TO PARTS LIST IN PAGE 3-17 FOR THIS P.W. BOARD.
REGULATOR P.W. BOARD ASS'Y (SFP-9203A-U2)
REFER TO PARTS LIST IN PAGE 3-18 FOR THIS P.W. BOARD.
LINE FILTER P.W. BOARD ASS'Y (SFP-9205A-U2)
ANALOG SIGNAL P.W. BOARD ASS'Y (SFP0A201A-U2)
REFER TO PARTS LIST IN PAGE 3-18 FOR THIS P.W. BOARD.
DIGITAL SIGNAL P.W. BOARD ASS'Y (SFP0D202A-U2)
R821 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R823 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R825 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R826 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R837 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R838 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R839 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R844 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R845 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R846 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R847 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R848 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R849 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R850 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R853 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R854 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R855 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R856 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R857 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R858 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R859 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R861 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R863 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R866 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R867 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R868 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R869 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R870 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R871 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R872 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R876 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R877 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R878 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R879 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R880 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R881 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R882 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R884 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R885 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R886 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R887 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R890 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R891 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R892 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R893 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R894 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R895 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R896 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R897 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R898 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R902 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R903 NRSA63J-561X MG RESISTOR 560 Ω 1/16W J
R904 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R906 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R908 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R910 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R911 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R912 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R913 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R923 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R926 NRSA63J-561X MG RESISTOR 560 Ω 1/16W J
R927 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R930 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R931 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R933 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R934 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R939 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R940 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R945 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R946 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R947 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R948 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R949 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R951 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R952 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R962 NRSA63J-682X MG RESISTOR 6.8k
Ω 1/16W J
R963 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R968 NRSA63J-123X MG RESISTOR 12k
Ω 1/16W J
R969 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R970 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R971 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R972 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R973 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R974 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R975 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R976 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R978 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
 Ref No. Part No. Part Name Description Local
R979 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R980 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R981 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
L801 NQR0351-001X FERRITE BEADS
L802 NQR0351-001X FERRITE BEADS
K801 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K803 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K804 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K805 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
X802 NAX0613-001X C RESONATOR
Y801 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
 Ref No. Part No. Part Name Description Local
 C9901 QFZ9073-225 MM CAPACITOR 2.2uF AC250V M
 C9912 QCZ9079-681 C CAPACITOR 680pF AC250V K
 C9913 QCZ9079-681 C CAPACITOR 680pF AC250V K
C9915 QFZ9075-224 MPP CAPACITOR 0.22uF AC275V M
 R9902 QRZ9046-105Z C RESISTOR 1M Ω 1/2W K
 F9901 QMFZ041-100-J1 FUSE 10A 250V
 J9901 QNC0099-001 AC INLET(NOISE) POWER CONNECTOR
 LF9901 QQR1281-002 LINE FILTER
 VA9901 ERZV10V621CS ZNR
LC32445-001B AC INLET BRACKET
 Ref No. Part No. Part Name Description Local
IC0401 SN74AHCT1G32V-X IC
IC1001 TC90A92AFG IC 100pin
IC1502 NJM2235V-X IC
IC3001 JCC5055 IC 438pin
IC3403 S-80928CLNB-W IC
 Ref No. Part No. Part Name Description Local
