JVC PD-35B50BJ - Interface P.w. Board Assy (Sfp-7202 A-U2)

(No.YA098)3-41
INTERFACE P.W. BOARD ASS'Y (SFP-7202A-U2)
R6529 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R6530 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R6531 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R6532 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R6533 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6534 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6535 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6536 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R6537 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R6538 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R6539 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R6540 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6541 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R6542 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6543 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R6551 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R6552 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R6553 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R6554 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R6555 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R6556 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R6557 NRSA63J-561X MG RESISTOR 560 Ω 1/16W J
R6558 NRSA63J-154X MG RESISTOR 150k Ω 1/16W J
R6559 NRSA63J-561X MG RESISTOR 560 Ω 1/16W J
R6560 NRSA63J-154X MG RESISTOR 150k Ω 1/16W J
R6563 NRSA63J-224X MG RESISTOR 220k
Ω 1/16W J
R6564 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R6567 NRSA63J-124X MG RESISTOR 120k Ω 1/16W J
R6568 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R6569 NRSA63J-823X MG RESISTOR 82k Ω 1/16W J
R6577 NRSA63J-183X MG RESISTOR 18k Ω 1/16W J
R6578 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R6579 NRSA63J-183X MG RESISTOR 18k Ω 1/16W J
R6580 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R6592 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R6593 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R6594 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R6595 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R6596 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R6601 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6602 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R6603 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R6605 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6606 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R6607 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R6617 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R6621 NRSA63J-121X MG RESISTOR 120 Ω 1/16W J
R6622 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6623 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R6624 QRJ146J-102X UNF C RESISTOR 1k Ω 1/4W J
R6625 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6626 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R6627 NRSA63J-224X MG RESISTOR 220k Ω 1/16W J
R6628 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R6629 NRSA63J-224X MG RESISTOR 220k Ω 1/16W J
R6630 NRSA63J-152X MG RESISTOR 1.5k
Ω 1/16W J
R6631 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6632 NRSA63J-392X MG RESISTOR 3.9k
Ω 1/16W J
R6633 NRSA63J-121X MG RESISTOR 120
Ω 1/16W J
R6634 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6635 QRN143J-0R0X C RESISTOR 0 Ω 1/4W J
R6661 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6662 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6663 NRSA63J-393X MG RESISTOR 39k
Ω 1/16W J
R6664 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R6665 NRSA63J-393X MG RESISTOR 39k
Ω 1/16W J
R6666 QRK126J-5R6X UNF C RESISTOR 5.6
Ω 1/2W J
R6667 QRK126J-220X UNF C RESISTOR 22
Ω 1/2W J
R6668 QRK126J-5R6X UNF C RESISTOR 5.6
Ω 1/2W J
R6669 QRK126J-220X UNF C RESISTOR 22
Ω 1/2W J
R6670 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R6671 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6673 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R6674 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R6675 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R6676 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R6677 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6679 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R6680 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6681 NRSA63J-563X MG RESISTOR 56k
Ω 1/16W J
R6682 NRSA63J-563X MG RESISTOR 56k Ω 1/16W J
R6683 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R6684 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R6685 NRSA63J-563X MG RESISTOR 56k Ω 1/16W J
R6686 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R6688 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R6689 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
 Ref No. Part No. Part Name Description Local
R6691 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
L6661 QQL28AK-560 COIL 56uH K
L6662 QQL28AK-560 COIL 56uH K
K6601 QQR0621-002Z FERRITE BEADS
K6602 QQR0621-002Z FERRITE BEADS
TH6401 NAD0035-471X P THERMISTOR 470 Ω
W6101 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W6102 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W6103 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W6104 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
Y6001 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
Y6002 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
Y6003 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
Y6004 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
Y6501 QRN143J-0R0X C RESISTOR 0 Ω 1/4W J
 Ref No. Part No. Part Name Description Local
IC103 BA05FP-X IC
IC801 BA033FP-X IC
IC802 BA033FP-X IC
IC805 AT24C16-35B50BJ IC (SERVICE)
IC807 HD6433685A30H IC(MCU) or HD64F3687A30H
IC809 S-80840CLNB-W IC
Q101 2SC3928A/QR/-X TRANSISTOR
Q803 2SA1530A/QR/-X TRANSISTOR
Q805 2SK2090-X MOS FET
Q806 2SK2090-X MOS FET
Q807 2SA1530A/QR/-X TRANSISTOR
Q811 2SK2090-X MOS FET
Q813 2SK2090-X MOS FET
Q814 2SK2090-X MOS FET
Q815 2SC3928A/QR/-X TRANSISTOR
D803 MA111-X SI DIODE
D804 MA8056/M/-X Z DIODE
D903 MA111-X SI DIODE
C114 NEH71AM-107X E CAPACITOR 100uF 10V M
C117 NEH70JM-107X E CAPACITOR 100uF 6.3V M
C802 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C803 NEH70JM-226X E CAPACITOR 22uF 6.3V M
C804 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C809 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C810 NEH70JM-107X E CAPACITOR 100uF 6.3V M
C814 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C815 NEH70JM-226X E CAPACITOR 22uF 6.3V M
C816 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C818 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C819 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C820 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C821 NEH71CM-106X E CAPACITOR 10uF 16V M
C825 NDC31HJ-220X C CAPACITOR 22pF 50V J
C826 NDC31HJ-220X C CAPACITOR 22pF 50V J
C828 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C829 NEH70JM-226X E CAPACITOR 22uF 6.3V M
C832 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
R104 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R105 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R106 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R402 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R801 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R802 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R803 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R804 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R806 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R807 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R808 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R809 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R810 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R811 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R812 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R813 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R814 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R815 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R816 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R817 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
 Ref No. Part No. Part Name Description Local
