JVC PD-35B50BJ - Regulator P.w. Board Assy (Sfp-9203 A-U2); Line Filter P.w. Board Assy (Sfp-9204 A-U2); Analog Signal P.w. Board Assy (Sfp0 A201 A-U2)

3-18(No.YA098)
REGULATOR P.W. BOARD ASS'Y (SFP-9203A-U2)
LINE FILTER P.W. BOARD ASS'Y (SFP-9204A-U2)
ANALOG SIGNAL P.W. BOARD ASS'Y (SFP0A201A-U2)
 Ref No. Part No. Part Name Description Local
IC9401 MP1580HS-X IC
IC9621 MP1410ES-X IC
IC9801 M62320FP-X IC
Q9211 2SB1188/QR/-W TRANSISTOR
Q9212 UN2213-X DIGI TRANSISTOR
Q9822 2SC3928A/QR/-X TRANSISTOR
D9401 EC30HA03L-X SB DIODE
D9403 PTZ11B-X Z DIODE
D9621 EC30HA03L-X SB DIODE
D9622 PTZ6.8B-X Z DIODE
D9822 MA8051/M/-X Z DIODE
D9823 MA111-X SI DIODE
C9402 NCJ41EK-106X-U C CAPACITOR 10mF 25V K
C9404 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9405 NCJ41CK-226X-U C CAPACITOR 22mF 16V K
C9407 NCB31HK-222X C CAPACITOR 2200pF 50V K
C9408 NCJ41CK-226X-U C CAPACITOR 22mF 16V K
C9622 NCJ41EK-106X-U C CAPACITOR 10mF 25V K
C9624 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9625 NCJ41CK-226X-U C CAPACITOR 22mF 16V K
C9627 NCB31HK-222X C CAPACITOR 2200pF 50V K
C9801 NCB11CK-105X C CAPACITOR 1uF 16V K
C9821 NCB11CK-105X C CAPACITOR 1uF 16V K
R9218 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R9219 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R9220 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R9231 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
R9401 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
R9402 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R9403 NRSA63J-183X MG RESISTOR 18k Ω 1/16W J
R9404 NRSA63D-104X MG RESISTOR 100k Ω 1/16W D
R9405 NRSA63D-184X MG RESISTOR 180k Ω 1/16W D
R9406 NRSA63D-103X MG RESISTOR 10k Ω 1/16W D
R9407 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R9408 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
R9621 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
R9622 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R9623 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R9624 NRSA63D-473X MG RESISTOR 47k Ω 1/16W D
R9625 NRSA63D-913X MG RESISTOR 91k Ω 1/16W D
R9626 NRSA63D-103X MG RESISTOR 10k Ω 1/16W D
R9627 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R9628 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
R9629 NRSA02J-471X MG RESISTOR 470 Ω 1/10W J
R9805 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R9806 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R9807 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R9809 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R9824 NRSA63J-563X MG RESISTOR 56k Ω 1/16W J
R9825 NRSA63J-822X MG RESISTOR 8.2k
Ω 1/16W J
R9826 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R9827 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
L9402 NQL71EM-150X COIL 15uH M
L9621 NQL71EM-150X COIL 15uH M
Y9601 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
 Ref No. Part No. Part Name Description Local
 C9901 QFZ9073-225 MM CAPACITOR 2.2uF AC250V M
 C9912 QCZ9079-681 C CAPACITOR 680pF AC250V K
 C9913 QCZ9079-681 C CAPACITOR 680pF AC250V K
C9916 QFZ9075-224 MPP CAPACITOR 0.22uF AC275V M
 R9902 QRZ9046-105Z C RESISTOR 1M Ω 1/2W K
 F9901 QMFZ041-100-J1 FUSE 10A 250V
 J9901 QNC0099-001 AC INLET(NOISE) POWER CONNECTOR
 LF9901 QQR1281-002 LINE FILTER
 VA9901 ERZV10V621CS ZNR
LC32445-001B AC INLET BRACKET
 Ref No. Part No. Part Name Description Local
IC201 TA1370FG-X IC
IC202 SN74AHC1G08V-X IC
IC301 AN15852A IC
IC501 CXA2069Q IC
IC502 MM1510XN-X IC
IC503 MM1510XN-X IC
IC604 RC4558D-X IC
IC605 AK4550VT-X IC
IC606 MM1562FF-X IC
IC607 NJU26103FR1 IC
IC711 CXA1875AM-X IC
IC801 TB1274AF IC
IC802 TC90A69AF-X IC
IC803 BA05FP-X IC
IC902 TA48M033F-X IC
Q307 2SA1530A/QR/-X TRANSISTOR
Q402 2SK1374-X MOS FET
Q403 2SK1374-X MOS FET
Q404 2SK1374-X MOS FET
Q405 2SK1374-X MOS FET
Q501 2SC3928A/QR/-X TRANSISTOR
Q502 2SC3928A/QR/-X TRANSISTOR
Q503 2SC3928A/QR/-X TRANSISTOR
Q504 2SC3928A/QR/-X TRANSISTOR
Q505 2SC3928A/QR/-X TRANSISTOR
Q506 2SC3928A/QR/-X TRANSISTOR
Q507 2SA1530A/QR/-X TRANSISTOR
Q508 2SA1530A/QR/-X TRANSISTOR
Q509 2SA1530A/QR/-X TRANSISTOR
Q511 UN2213-X DIGI TRANSISTOR
Q512 2SC3928A/QR/-X TRANSISTOR
Q513 2SC3928A/QR/-X TRANSISTOR
Q602 2SC3928A/QR/-X TRANSISTOR
Q605 2SC3928A/QR/-X TRANSISTOR
Q606 2SC3928A/QR/-X TRANSISTOR
Q607 2SC3928A/QR/-X TRANSISTOR
Q801 2SA1530A/QR/-X TRANSISTOR
Q802 2SA1530A/QR/-X TRANSISTOR
Q810 2SA1530A/QR/-X TRANSISTOR
Q851 2SA1530A/QR/-X TRANSISTOR
Q853 2SC3928A/QR/-X TRANSISTOR
Q854 2SC3928A/QR/-X TRANSISTOR
Q855 2SA1530A/QR/-X TRANSISTOR
Q858 2SC3928A/QR/-X TRANSISTOR
Q859 2SA1530A/QR/-X TRANSISTOR
Q862 2SC3928A/QR/-X TRANSISTOR
Q863 2SC3928A/QR/-X TRANSISTOR
Q901 2SC3074/OY/-X TRANSISTOR
QB613 2SC3928A/QR/-X TRANSISTOR
QB614 2SA1530A/QR/-X TRANSISTOR
D501 MA8100/M/-X Z DIODE
D651 MA8047/L/-X Z DIODE
D652 MA111-X SI DIODE
D903 PTZ11B-X Z DIODE
D904 PTZ6.8B-X Z DIODE
DB201 MA8033-X Z DIODE
DB601 MA111-X SI DIODE
DB602 MA111-X SI DIODE
DB603 MA111-X SI DIODE
DB604 MA111-X SI DIODE
DB605 MA111-X SI DIODE
DB606 MA111-X SI DIODE
DB607 MA111-X SI DIODE
DB701 MA8051/M/-X Z DIODE
C201 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C202 NEH71HM-225X E CAPACITOR 2.2uF 50V M
C203 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C204 NEH71AM-107X E CAPACITOR 100uF 10V M
C205 NEH71HM-105X E CAPACITOR 1uF 50V M
C206 NCB11CK-105X C CAPACITOR 1uF 16V K
C207 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C301 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C302 NEH71CM-476X E CAPACITOR 47uF 16V M
C303 NCB21CK-105X C CAPACITOR 1uF 16V K
C304 NCB21CK-105X C CAPACITOR 1uF 16V K
C305 NCB21CK-105X C CAPACITOR 1uF 16V K
C319 NEH71CM-476X E CAPACITOR 47uF 16V M
C320 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C321 NEH71CM-106X E CAPACITOR 10uF 16V M
C322 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C323 NEH71CM-476X E CAPACITOR 47uF 16V M
C324 NCB11CK-105X C CAPACITOR 1uF 16V K
