JVC PD-35B50BJ - Page 70

3-16(No.YA098)
C9005 QEZ0709-106 E CAPACITOR 10uF
 C9014 QFZ9072-105 MM CAPACITOR 1uF AC250V K
 C9019 QFZ9072-474 MM CAPACITOR 0.47uF AC250V K
C9020 QFZ0128-474 MPP CAPACITOR 0.47uF DC400V H
C9021 QEZ0601-187 E CAPACITOR 180uF 450V M
C9022 QEZ0601-187 E CAPACITOR 180uF 450V M
C9023 QEHR1HM-105Z E CAPACITOR 1uF 50V M
C9024 NCB31HK-153X C CAPACITOR 0.015uF 50V K
C9025 NDC31HJ-471X C CAPACITOR 470pF 50V J
C9027 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9028 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9029 NCF31CZ-334X C CAPACITOR 0.33uF 16V Z
C9030 QEHR1VM-107Z E CAPACITOR 100uF 35V M
C9031 NCB31CK-154X C CAPACITOR 0.15uF 16V K
C9032 NDC31HJ-680X C CAPACITOR 68pF 50V J
C9033 NDC31HJ-471X C CAPACITOR 470pF 50V J
C9034 NCB31HK-152X C CAPACITOR 1500pF 50V K
C9201 QEHR1HM-105Z E CAPACITOR 1uF 50V M
C9202 NDC31HJ-471X C CAPACITOR 470pF 50V J
C9203 QCZ0340-471 C CAPACITOR 470pF 2kV K
C9204 QEHR1VM-476Z E CAPACITOR 47uF 35V M
C9205 NCB31HK-102X C CAPACITOR 1000pF 50V K
C9207 QFP32JK-332 PP CAPACITOR 3300pF 630V K
C9208 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9210 QEHR1VM-476Z E CAPACITOR 47uF 35V M
C9213 QEHQ2AM-477 E CAPACITOR 470uF 100V M
C9214 QEHQ2AM-477 E CAPACITOR 470uF 100V M
C9215 QECQ1EM-228 E CAPACITOR 2200uF 25V M
C9216 QEHR1VM-477Z E CAPACITOR 470uF 35V M
C9217 QFLC2AJ-104Z M CAPACITOR 0.1uF 100V J
C9220 NCB31HK-153X C CAPACITOR 0.015uF 50V K
C9221 QECR1EM-687Z E CAPACITOR 680uF 25V M
C9223 QEZ0256-128 E CAPACITOR 1200uF 10V M
C9227 QEHR1HM-107Z E CAPACITOR 100uF 50V M
C9401 QCZ0340-152 C CAPACITOR 1500pF 2kV K
C9402 QFZ0219-105 MPP CAPACITOR 1uF 400V J
C9403 NDC31HJ-150X C CAPACITOR 15pF 50V J
C9404 NDC31HJ-181X C CAPACITOR 180pF 50V J
C9405 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9406 QCZ0340-471 C CAPACITOR 470pF 2kV K
C9408 NDC31HJ-100X C CAPACITOR 10pF 50V J
C9410 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9411 NCB31HK-333X C CAPACITOR 0.033uF 50V K
C9412 QECR1EM-476Z E CAPACITOR 47uF 25V M
C9414 QEZ0599-108 E CAPACITOR 1000uF 200V M
C9415 QEZ0599-108 E CAPACITOR 1000uF 200V M
C9416 QFP32GJ-393 PP CAPACITOR 0.039uF 400V J
C9417 NCB31HK-821X C CAPACITOR 820pF 50V K
C9601 QCZ0340-471 C CAPACITOR 470pF 2kV K
C9602 NCB31HK-152X C CAPACITOR 1500pF 50V K
C9603 QEHR1HM-226Z E CAPACITOR 22uF 50V M
C9604 NDC31HJ-561X C CAPACITOR 560pF 50V J
C9606 QEHR2AM-107Z E CAPACITOR 100uF 100V M
C9607 QEHR1HM-475Z E CAPACITOR 4.7uF 50V M
C9608 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9611 QCZ0340-471 C CAPACITOR 470pF 2kV K
C9612 NDC31HJ-471X C CAPACITOR 470pF 50V J
C9613 QEHR1HM-226Z E CAPACITOR 22uF 50V M
C9614 NCB31HK-102X C CAPACITOR 1000pF 50V K
C9615 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9616 QEHR2DM-226Z E CAPACITOR 22uF 200V M
C9621 QCZ0340-471 C CAPACITOR 470pF 2kV K
C9622 NDC31HJ-471X C CAPACITOR 470pF 50V J
C9623 QEHR1HM-226Z E CAPACITOR 22uF 50V M
C9624 NCB31HK-102X C CAPACITOR 1000pF 50V K
C9625 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9626 QEHR2DM-226Z E CAPACITOR 22uF 200V M
C9627 NCB31HK-222X C CAPACITOR 2200pF 50V K
C9628 NCB31HK-222X C CAPACITOR 2200pF 50V K
C9630 NCB31HK-222X C CAPACITOR 2200pF 50V K
C9631 QEHR1VM-227Z E CAPACITOR 220uF 35V M
C9632 QEHR1EM-227Z E CAPACITOR 220uF 25V M
C9633 QECR1EM-687Z E CAPACITOR 680uF 25V M
C9635 QECR1AM-128Z E CAPACITOR 1200uF 10V M
 R9001 QRZ0057-825 C RESISTOR 8.2M Ω 1W J
R9003 QRX01GJ-1R0 MF RESISTOR 1 Ω 1W J
R9004 QRX01GJ-R82 MF RESISTOR 0.82
Ω 1W J
R9007 QRE121J-151Y C RESISTOR 150 Ω 1/2W J
R9008 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R9009 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R9010 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R9011 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
 R9012 QRZ9055-4R7 FUSI RESISTOR 4.7 Ω 2W K
R9013 QRZ0216-4R7 UNF WW RESISTOR 4.7 Ω 7W K
R9015 QRE121J-224Y C RESISTOR 220k
Ω 1/2W J
R9016 QRE121J-224Y C RESISTOR 220k
Ω 1/2W J
 Ref No. Part No. Part Name Description Local
 R9017 QRZ9009-220 FUSI RESISTOR 22 Ω 1/2W J
 R9018 QRZ9017-4R7 FUSI RESISTOR 4.7 Ω 1/4W J
R9019 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R9020 QRE121J-331Y C RESISTOR 330 Ω 1/2W J
 R9021 QRZ9017-4R7 FUSI RESISTOR 4.7 Ω 1/4W J
R9022 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R9024 QRM059J-R15 MP RESISTOR 0.15 Ω 5W J
R9025 QRM059J-R15 MP RESISTOR 0.15 Ω 5W J
R9029 NRS144F-124X MG RESISTOR 120k Ω 1/4W F
R9030 NRS144F-124X MG RESISTOR 120k Ω 1/4W F
R9031 NRS144F-224X MG RESISTOR 220k Ω 1/4W F
R9032 NRS144F-224X MG RESISTOR 220k Ω 1/4W F
R9033 NRS144F-124X MG RESISTOR 120k Ω 1/4W F
R9034 NRS144F-124X MG RESISTOR 120k Ω 1/4W F
R9035 QRE121J-472Y C RESISTOR 4.7k Ω 1/2W J
R9036 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R9037 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R9038 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R9040 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R9045 NRSA63J-270X MG RESISTOR 27 Ω 1/16W J
R9046 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R9047 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R9048 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R9049 QRK126J-820X UNF C RESISTOR 82 Ω 1/2W J
R9051 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R9052 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R9053 NRSA63J-394X MG RESISTOR 390k
Ω 1/16W J
R9054 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R9056 NRSA63D-152X MG RESISTOR 1.5k Ω 1/16W D
R9057 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R9060 NRSA63D-222X MG RESISTOR 2.2k Ω 1/16W D
R9061 QRZ0216-4R7 UNF WW RESISTOR 4.7 Ω 7W K
R9062 QRE121J-100Y C RESISTOR 10 Ω 1/2W J
R9063 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R9065 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R9066 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R9201 QRL039J-563 OMF RESISTOR 56k Ω 3W J
R9202 QRL039J-563 OMF RESISTOR 56k Ω 3W J
R9204 QRT029J-R27 MF RESISTOR 0.27 Ω 2W J
R9205 QRK126J-101X UNF C RESISTOR 100 Ω 1/2W J
R9206 QRE121J-182Y C RESISTOR 1.8k Ω 1/2W J
R9207 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R9208 QRE121J-684Y C RESISTOR 680k Ω 1/2W J
R9209 QRL039J-220 OMF RESISTOR 22 Ω 3W J
 R9210 QRZ9009-100 FUSI RESISTOR 10 Ω 1/2W J
R9211 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R9212 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R9213 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R9214 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R9216 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R9217 QRE121J-102Y C RESISTOR 1k Ω 1/2W J
R9218 QRE121J-124Y C RESISTOR 120k Ω 1/2W J
R9219 QVP0087-202Z TRIM RESISTOR Va VR 2k Ω 0.3W N
R9220 NRSA63D-472X MG RESISTOR 4.7k Ω 1/16W D
R9221 NRSA63J-123X MG RESISTOR 12k Ω 1/16W J
R9225 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R9239 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R9240 QRE121J-273Y C RESISTOR 27k
Ω 1/2W J
R9241 NRSA63J-273X MG RESISTOR 27k
Ω 1/16W J
R9243 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R9266 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R9267 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R9268 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R9269 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R9270 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R9271 QRL039J-682 OMF RESISTOR 6.8k
Ω 3W J
R9401 QRE121J-824Y C RESISTOR 820k
Ω 1/2W J
R9402 QRL039J-220 OMF RESISTOR 22
Ω 3W J
R9403 QRL039J-563 OMF RESISTOR 56k
Ω 3W J
R9404 QRM059J-R22 MP RESISTOR 0.22
Ω 5W J
R9405 QRT029J-3R9 MF RESISTOR 3.9
Ω 2W J
R9406 QRE121J-120Y C RESISTOR 12 Ω 1/2W J
R9407 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R9408 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R9409 NRSA63J-274X MG RESISTOR 270k Ω 1/16W J
R9411 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R9413 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R9414 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
 R9415 QRZ9017-470 FUSI RESISTOR 47 Ω 1/4W J
R9416 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R9417 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R9418 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R9420 NRS12BJ-823W MG RESISTOR 82k
Ω 1/2W J
R9421 NRS12BJ-562W MG RESISTOR 5.6k Ω 1/2W J
R9422 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R9423 NRS12BJ-823W MG RESISTOR 82k
Ω 1/2W J
R9424 QVP0087-501Z TRIM RESISTOR Vs VR 500
Ω 0.3W N
 Ref No. Part No. Part Name Description Local
