1-2 (No.YA098)
Dimensions (W x H x D)
104.5cm x 72.9cm x 11.0cm 90.7cm x 63.4cm x 11.7cm
Mass 38.3kg 30.4kg
TV RF System CCIR B / G, I, D / K, L
Colour System RF PAL / SECAM
EXT PAL / SECAM / NTSC3.58 / NTSC4.43
Stereo System A2 (B / G, D / K), NICAM (B / G, I, D / K, L)
Teletext System FLOF (Fastext), TOP, WST (World Standard System)
Receiving Frequency VHF 47MHz ~ 470MHz
UHF 470MHz ~ 862MHz
CATV 116MHz ~ 172MHz, 220MHz ~ 469MHz
Intermediate Frequency VIF 38.9MHz (B / G, I, D / K, L)
SIF
33.4MHz (5.5MHz: B / G) / 32.9MHz (6.0MHz: I) / 32.4MHz (6.5MHz: D / K) /
40.45MHz (6.5MHz :L)
Colour Sub Carrier Frequency
PAL : 4.43MHz
SECAM : 4.40MHz / 4.25MHz
NTSC : 3.58MHz / 4.43MHz
Power Input AC110V ~ AC240V, 50Hz
Power Consumption Operate : 303W, Stand by: 3.0W Operate : 244W, Stand by : 3.0W
Plasma Display Panel (PDP) QLE0028-001 QLE0021-002
42V wide aspect (16:9) 35V wide aspect (16:9)
Screen Size Visible size : 107.5cm (Diagonel) / Visible size : 91.0cm (Diagonel) /
93.3 cm x 53.3 cm (H x V) 78.6 cm x 44.2 cm (H x V)
Display Pixels
H: 852 pixels / V: 480 pixels H: 853 pixels / V: 480 pixels
[W-VGA] [W-VGA]
Speaker 6.6cm round x4
Audio Power Output 10W + 10W (Oblique cone)
Aerial Input Teminal 75
Ω
unbalanced, coaxial
External EXT-1 (Input/Output) 21 pin Euro connector (SCART socket)
terminal
• Video input, S-video (Y / C) input, Audio L / R inputs and RGB inputs
are available.
•
TV broadcast outputs (Video and Audio L / R) are available.
EXT-2 (Input/Output) 21 pin Euro connector (SCART socket)
•
Video input, S-video (Y / C) input, Audio L / R inputs and RGB inputs
are available.
•
Video and Audio L / R outputs are available.
•
T-V LINK functions are available.
EXT-3 (Input) 21 pin Euro connector (SCART socket)
•
Video input and Audio L / R inputs are available.
EXT-4 (Input) COMPONENT VIDEO RCA pin jack x 3
1125i / 750p Y : 1V(p-p), Sync
±0.35V(p-p) terminal x3
, 75
Ω
Pb/Pr :
±
0.35V(p-p), 75
Ω
525i / 525p / 625i / 625p
Y : 1V(p-p), Positive (Negative sync prorided), 75
Ω
Cb/Cr :
0.7
V(p-p), 75
Ω
AUDIO 500mV (rms), High impedance, RCA pin jack x 2
EXT-5 (Input) S-VIDEO Mini-DIN 4 pin x 1
Y : 1V(p-p), Positive (Negative sync provided), 75
Ω
C : 0.286V(p-p) (Burst signal), 75
Ω
VIDEO 1V(p-p), Positive (Negative sync provided), 75
Ω
, RCA pin jack x 1
AUDIO 500mV (rms), Low impedance, RCA pin jack x 2
AUDIO OUTPUT (Fixed) 500mV (rms), Low impedance, RCA pin jack x 2
Subwoofur OUTPUT 500mV (rms), Low impedance, RCA pin jack x 1
CENTRE CH INPUT 500mV (rms), Low impedance, RCA pin jack x 1
PC (RGB) INPUT D-sub 15pin x 1
R/G/B : 0.7V (p-p), 75
Ω
HD / VD : 1V (p-p) ~ 5V (p-p), High impedance
Available signal
VGA : 640 pixels x 480 pixels (Horizontal : 31.5kHz / Vertical : 60Hz)
Headphone 3.5mm Stereo mini jack x 1
Remote Control Unit RM-C1811H (AA/R6 TYPE battery x 2)
SPECIFICATION
Contents
Design & specifications are subject to change without notice.
Items
PD-42B50BJ PD-35B50BJ
PD-42B50BU PD-35B50BU
