Components and functions
Open the CD compartment
Turnthelock(1)slightly90degreescounter-clockwiseto
open the CD compartment.
Toclosethelid,closeitbyhanduntilthelockengages
again.
1
Mounting the carrying strap
1.Takeoneendofthestrapwiththehempointingupwards,and
threaditfrombelowintothebuckle(1).Pleasepayattentiontothe
correct alignment of the buckle. Insert the strap from above into the
secondopeningofthestrapbuckle(2)andpullthestrapoutofthe
buckleapprox.20cm.
2.Theendofthestrapisnowinsertedintothecasing
holder(3)andpulledoutofthesecondcasingholder(4).
3.Threadthestrapbackthroughthebuckle,pushingin
theendoverthepreviousbeltrout.Tightenthestrap,
making sure the strap can not slip out of the buckle. With
theothersideofthebeltpleaseproceedtopoint1.
