200 JVL Industri Elektronik A/S - User Manual - Ethernet for MAC and MIS motors
8.3 Sercos Communication
IDN Description Default Units Attri-
butes
S-0-1023 Sync jitter - - RW
S-0-1024 SYNC delay measuring procedure command - - RW
S-0-1026 Version of communication hardware - - RO
S-0-1027.0.1 Requested MTU - - RW
S-0-1027.0.2 Effective MTU - - RO
S-0-1028 Error counter MST - - RO
S-0-1031 Test pin assignment port 1 & port 2 - - RW
S-0-1032 Communication control - - RW
S-0-1035 Error counter port 1 & port 2 - - RW
S-0-1035.0.1 Error counter P&S - - RO
S-0-1036 Interframe gap - - RW
S-0-1037 Slave jitter - - RO
S-0-1039 Hostname - - RW
S-0-1035.0.1 Current hostname - - RO
S-0-1040
Sercos
®
address
- - RW
S-0-1041 AT command valid time (t9) - - RW
S-0-1044 Device control - - RO
S-0-1045 Device status - - RO
S-0-1046 List of Sercos® addresses in device - - RO
S-0-1047 Maximum consumer activation time (t11) - - RO
S-0-1048 Activate network settings procedure command - - RW
S-0-1050.0.1 Connection setup - - RW
S-0-1050.0.2 Connection number - - RW
S-0-1050.0.3 Telegram assignment - - RW
S-0-1050.0.4 Max. length of connection - - RO
S-0-1050.0.5 Current length of connection - - RO
S-0-1050.0.6
Mapped cyclic consumer data (AT data = cyclic data
from motor to PLC)
- - RW
S-0-1050.0.8 Connection control - - RO
S-0-1050.0.10 Producer cycle time - - RW
S-0-1050.0.11 Allowed data losses - - RW
S-0-1050.0.12 Error counter data losses - - RO
S-0-1050.0.20
(3,4)
IDN allocation of real time bit - - RW
S-0-1050.0.21
(3,4)
Bit allocation of real time bit - - RW
S-0-1050.1.1 Connection setup - - RW
S-0-1050.1.2 Connection number - - RW
S-0-1050.1.3 Telegram assignment - - RW
S-0-1050.1.4 Max. length of connection - - RO
S-0-1050.1.5 Current length of connection - - RO
S-0-1050.1.6
Mapped cyclic producer data (MDT data = Cyclic data
from PLC to motor)
- - RW
S-0-1050.1.8 Connection control - - RO
S-0-1050.1.10 Producer cycle time - - RW
S-0-1050.1.11 Allowed data losses - - RW
S-0-1050.1.12 Error counter data losses - - RO
S-0-1300.0.1 Component name
MAC00_ES
_DRIVE
-RO
S-0-1300.0.2 Vendor name JVL - RO
S-0-1300.0.3 Vendor code 279 - RO
S-0-1300.0.4 Device name
MAC00-ES-
FSPDrive
- RO
