JVL Industri Elektronik A/S - User Manual - Ethernet for MAC and MIS motors 243
10.2 Setting up the Ethernet at the PC
10.2.1 Setting up the PC for EthernetIP, Profinet, ModbusTCP or Sercos.
When a connection is made directly from the PC it is very important to observe the IP-
settings of the PC, since the most common way is for the PC to receive the settings from
a server such as a DHCP/server or similar.
Since the motor doesn’t offer any DHCP service it is necessary to setup the IP-address
in the PC manually.
Please note that this is taken from Windows 7, but the method is basically the same for
other Windows version.
To reach the IP settings please follow this path:
Step 1.
PresstheLAN‐Connectionandpressthe“Properties”.
Continued next page
Follow this path to find the network settings
Find the «LAN-Connection»
LAN-connection
To Next Page
