Kaba E-Plex 50 Series - Visual Fe 4.E 4.Dback Me 4.Ssage 4. De 4.Finitions

33
Visual Feedback Message Definitions
Condition Parameters
Green LED Red LED Duration Rate
Valid pushbutton pressed ON OFF 1/10 sec Once
Timeout expired OFF ON 1 sec Once
Valid access code keyed ON OFF 1 sec Once
Access granted ON OFF 1/10 sec 1 sec
Access granted
(battery low condition)
ON ON 1/10 sec 1 sec
Access denied OFF ON 1 sec Once
Valid programming entry ON OFF 1 sec Once
Invalid programming
entry (including duplicate
access code
OFF ON 1 sec Once
Tamper shutdown beginning OFF ON 2 sec Once
Tamper shutdown state OFF ON 1 sec 10 sec
Tamper shutdown ending ON OFF 2 sec Once
Communication starting ON OFF 1 sec Once
Communication ending ON OFF 1 sec Once
Communication aborted OFF ON 1 sec Once
Communication in progress ON
(Alternate)
ON
(Alternate)
1/10 sec Continuously
Hard Reset sequence in progress ON
(Alternate)
ON
(Alternate)
1/2 sec Once
Hard Reset sequence
successfully
ON OFF 2 sec Once
Hard Reset sequence failed OFF ON 2 sec Once
