Kaba E-Plex 50 Series User Manual

9
5. After the 15 minutes delay has exhausted, the Reset sequence in
progress message will be displayed on the LEDs again for 20 seconds.
During this period, the user must enter the 1-2-3-4-5-6-7-8-# sequence
and the lock will reset. If the user fails to do so, the sequence will
abort and the lock will resume normal operation.
*M-Unit is only applicable when using optional E-Plex software.
PROCEDURE 1 - PROGRAM THE ACCESS CODE LENGTH
Setting the length of Access Codes must be the first lock programmable func-
tion you perform, because all your other access codes must have the same
length. If a user enters a code of a different length, the lock will not accept it.
Longer length Access Codes permit a greater number of code possibilities, and
thus higher security. The master code must always be 8 digits. This length can
not be changed.
Required User Level: Master
1. To configure the E-Plex Lock programmable pushbutton lock, it must first
be placed in Programming Mode.
Important: This is the only programmable function that can be done
during the factory mode using the factory master code. Except for
changing from the factory code to a new master code.
2. Enter the E-Plex Lock factory Master (Programming) Code
(#12345678#). The lock responds with a flashing green light.
If 1-2-3-4-5-6-7-8 does not seem to work, please follow the steps
to perform a hard reset by following the procedure in on page 6.
3. Enter the code 009 #LL #, where LL represents the length (number of
digits in a code). The range is from 04 to 08 digits. You can leave the
factory default Access Code length (4 digits) if you wish by not
changing the length.
4. Example of Complete Entry: 009#05# to change the code length to 5
digits.
5. Key in another # to indicate the end of programming.
6. From now on, all the Access Codes you create must be the length
specified in this step.

Kaba E-Plex 50 Series Specifications

General

Housing Material	Metal
Type	Electronic Lock
Lock Type	Mortise Lock
Programming	Via keypad
Dimensions	Varies by Model
Weight	Varies by Model
Weather Resistance	IP54
Operating Temperature	-40°C to 70°C
Locking Direction	Reversible
Protection Class	IP54
Mounting	Mortise
Compatibility	Standard Door Preparations
