INSTALLATION GUIDE - REMOTE ACCESS CONTROLLER RAC 4XT • PK3191_10_14
6.0 Annex H Drilling Template for Contactless Card Reader
4X R9/32 [7,1]
REF
1-11/16
[42,9]
17/32
[13,5]
1-7/8
[47,6]
REF
2-7/8
[73]
REF
HOLE
ID
DIM
COMMENTS INCH[mm]
INCH [mm]
A
INSTALLATION WITH DRYWALL INSERT
7/32 5,6 1-1/2 [38,1]
INSTALLATION WITH METAL SCREW
9/64 3,6 1/2 [12,7]
B
5/8 15.9 -
DRILLING TEMPLATE
RFID WALL READER R79K
SURFACE MOUNT MODULE
SHEET
DATE
21AU14
UNE VERSION FRANCAISE DE CE DOCUMENT
EST DISPONIBLE SUR DEMANDE.
1 OF 1
ECN
15174
DT-514800
REV-1
R
7301, Décarie Boul.
Montréal, Qc, Canada
H4P 2G7
www.kaba-ilco.com
A
A
B
DO NOT REPRODUCE
CONTACT CUSTOMER SUPPORT
1-800-906-4526
