INSTALLATION GUIDE - REMOTE ACCESS CONTROLLER RAC 4XT • PK3191_10_14
3.1 Parts and Tools List
NOTE:
- Some items are dependant on the
options or configuration purchased.
Please ensure all parts ordered &
required for installation are available
before beginning.
- Parts are subject to change without
notice.
- For letter designations refer to Figure 9.
RAC 4XT Enclosure:
NOTE: All items above come factory
installed.
(A) RAC 4XT enclosure with access door
(B)
Power supply: 24 VAC / 24 VDC input,
12 VDC output
(C) Controller PCB
(D)Tamper switch
(E) 2 panel-mounted LEDs (green) for
power & battery status
(F) Cam-lock
Battery back-up (optional):
NOTE: All items come factory installed
where ordered with initial system.
(G) 1x lead acid battery including:
- 2x strapping bracket
- 2x flat washer (#8)
- 2x split washer (#8)
- 2x nut (#8-32)
- Power supply cabling (1x red, 1x
black – 18 AWG, ~10”)
Relay Expansion Board (optional):
NOTE: All items come factory installed
where ordered with initial system.
(H) Relay expansion PCB board including
4x 6-32 x 3/8” SS screw with washer
& controller PCB connection cable
(not shown)
Cables (not shown):
NOTE: Some items come factory
installed.
(I) System cables:
- Power supply to LEDs
- Power supply to controller PCB
- Controller PCB jumpers (card
reader type dependent)
Card Reader(s):
NOTE: Type of card reader(s) dependent
on system configuration ordered.
(J) Swipe reader (see Figure 4)
(J) Insert reader (see Figure 6) – may
require additional tools as per PK3166
included with the reader.
(J) Contactless reader (see Figure 7)
Locking Device
NOTE: Locking device(s) dependent on
system configuration ordered.
(K) Electric strike
(L) Electromagnetic Lock
Power Adaptor includes:
NOTE: Dependent on country’s electrical
power requirements.
(M) 1x International 24 VDC output adaptor
with integrated 6 foot (1.8 m) power
cable and interchangeable AC outlet
prongs. Input power requirements of
220-240 VAC, 50-60 Hz.
or
(N) 1x North America 24 VAC output
power adaptor, with 2 separate 10
foot (3 m) power cable assembly (2x
18 AWG cables terminated on one
end with fork terminals). Input power
requirements of 110-120 VAC, 60 Hz.
Other Peripherals (optional):
(O) Request to Exit button
(P) Remote Programming Interface (RPI)
(Q) Remote Unlock (Not shown)
Programming Device
NOTE: Purchased separately, dependent
on hotel configuration.
IMPORTANT:
Programming of the RAC 4XT can only
be done with the following versions of
programming device software:
- ATLAS: software version 1.0 or higher
- Kaba Ilco 780 FDU: software version
6.40 or higher
- Kaba Ilco FDU 4 (G4): all versions
(R) Front Desk Unit (FDU)
(R) ATLAS with Infra-red Programming
Module (IPM)
3.0 Checklist and Exploded Views
