Page 7
INSTALLATION GUIDE - REMOTE ACCESS CONTROLLER RAC 4XT • PK3191_10_14
Installation Hardware Bag:
(S) 4x Philips wood screw, #8 x 1–1/4”
(T) 4x Nylon anchor, #6–10
(U) 4x Concrete anchor, #7–9
(V) 2x Strain relief connector with locking
nut
(W) 2x Diode-rectifier
(X) 5x Steel flat washer, #8
(Y) 3x Crimp terminal B connector
(Z) 2x Crimp fork terminals, 18–22 AWG
Tools required (not supplied):
Additional tools may be required
dependent on the peripherals being
installed. The list below covers the
installation of the RAC 4XT enclosure
only.
• Safety glasses
• Ink marker
• Electric drill
• 9/64” (3.5 mm) drill bit
• 7/32” (5.5 mm) drill bit
• 1/4” (6.5 mm) drill bit
• 3/8” (9.5 mm) drill bit
• Philips screwdriver – #2
• Slotted screwdriver – 3/32” tip width
• Adjustable wrenches
• Crimp tool – 18-22 AWG
• Pliers
• Wire cutter / stripper
• FDU/ATLAS programmed “Test Lock”
keycard
• Hammer or rubber mallet
• Awl or center punch
3.0 Checklist and Exploded Views
