Technical Specification
2 --- 3
2 Technical Specification
Model designation and important technical information is found on the machine’s name-
plate. The nameplate is located on the outside of the machine:
above the cooler, or
on the rear of the machine.
Please enter here the data from the nameplate:
Model
Material (part) no.
Serial no.
Year of manufacture
Rated power
Motor speed
Maximum working pressure
Ambient temperature
Tab. 1 Nameplate
A summary of the included options helps to relate the service manual information to your
machine.
Please enter details of options.
Option
Code Exists
Air cooling K1
Water cooling K2
Cooling air filter mat K3
Machine mountings H1
Prepared for heat recovery W1
Internal heat recovery
T= 25K W2
Internal heat recovery
T= 55K W3
Modulating control C1
Transformer power supply for refrigeration
dryer
T2
Tab. 2 Options
2.1 Weight
Maximum weights are shown. Actual weights of individual machines are dependent on
equipment fitted.
CSD 82 CSD 102 CSD 122
Weight [kg] 1300 1350 1400
Tab. 3 Machine weights
