13. Assemble the water distributor to the
dispenser valve, and lock the screws on
both sides uniformly, the head of the
screws need loctite.
14. Assemble the water dispenser box and
the gear box together, and then lock the
screw.
1. When installing the support seal, the
downside should be with bigger diameter.
1. Install the piston and release link into the coffee brewing unit, oil(MI-setral-61B) coating position
should be as the picture shows.
Valve support group
Brew unit
