4. Put the already installed epicyclic gear
frame A into the gearbox, put 1 filler piece
onto epicyclic gear frame A.
5. Put the already installed epicyclic gear
frame B into gearbox.
6. Put the steel ball support and 34 roll steel
ball into gearbox.
7. Install 3 grinder antivibration pads and 3
antivibration bushes into coffee powder
container.
9. Install the line pencil into the grinder motor,
red line correspond to the red mark.
Note: The installation direction for
the grinder antivibration pads and 3
antivibration bushes.
