KANE905 Operators Manual Page 20
6. MENU OPTIONS AND SETTINGS
MAIN MENU
The MAIN MENU consists of 4
sub menus:
MAIN MENU
1. SELECT
3. DISPLAY
2. UNITS
4. SETUP
All sub-menus are accessed using and exited using .
The and keys move the cursor within a menu and allow
parameters to be changed.
TIP: Holding down one of these keys scrolls through the data quicker.
SUB MENU - 1. SELECT
Page 1:
FUEL
: NATURAL GAS
O2 Ref
: OFF
SMOKE
: OFF
RESET
: NO

Page 2:
PITOT
: 1.00

This menu allows selections to be made for the parameters detailed
below.
FUEL : Select the fuel being used by the boiler from either a standard
fuel stored in the analyser or by entering the user fuel. Once
the correct fuel has been selected press to view the
fuel constants.
NATURAL GAS
K1g
: 0.350
K1n
: 0.390
K_2
: 11.89
K_3
: 9.83
K_4
: 32
O2r
: 3.0
