4K/60 2x1 Wall Plate Switcher & Extender Set
13
② When control the far-end third party device from local control device (e.g. PC),
please connect the PC to the RS232 port of the transmitter, and then please
connect the third party device (e.g. projector) to the RS232 port of receiver. The
connection diagram shown as below:
P
o
C
IN
H
D
B
T
O
U
T
Projector
RS232:
HDBT:
Receiver
Transmitter
PoC
PC
Power
RS232
