4K/60 2x1 Wall Plate Switcher & Extender Set
14
③ When control the local third party device from far-end control device (e.g. PC),
please connect the PC to the RS232 port of the receiver, and then please connect
the third party device to the RS232 port of transmitter. The connection diagram
shown as below:
P
o
C
IN
H
D
B
T
O
U
T
PC
Third Party Device
RS232:
HDBT:
Receiver
Transmitter
PoC
Power
RS232
