KaVo ABSORmatic plus - Category use C:

Category use C:
Suitable for separation of dusts with maxi-
mum workplace concentrations and of car-
cinogenic substances (§ 35 of German
Regulation on Dangerous Substances), with
the exception of particularly dangerous car-
cinogenic substances (§ 15a of German
Regulation on Dangerous Substances).
Filter area 1,4 m2
Max. reduced pressure 180 mbar
Suction power:
Stage I approx. 60-86 unit
Stage II approx. 90-129 unit
Stage III approx. 135-167 unit
Stage IV approx. 141-191 unit
(1 unit = 0.9 - 1.0 m3/h
Noise emission values:
Single coll. Triple coll.
Stage I 57 dB (A)
Stage II 62 dB (A)
Stage III 64 db (A)
Stage IV 68 db (A)
Suction connection
Dust collector: ∅ 50 mm
Suction nozzles: ∅ 42 or 50 mm
Hose (internal) ∅ 42 or 50 mm
Suction hose length: max. 5 000 mm
We reserve the right to make any alter-
ations.
