KaVo ABSORmatic plus - A 11 Technical data

34
ABSORmatic
®
plus.
A 11 Technical data
Dimensions and weights
Width: 225 mm
Depth: 600 mm
Height: 760-790 mm (type 9047)
835-865 mm (type 9048)
910-940 mm (type 9049)
(30 mm adjustment range)
Dust extraction collector ABSORmatic

-
plus 9047 48 kg
Dust extraction collector ABSORmatic

-
plus 9048 49 kg
Dust extraction collector ABSORmatic

-
plus 9049 50 kg
Rated voltages
Voltage ranges: 100 V 50-60 Hz
120 V 60 Hz
230 V 50-60 Hz
Rated power:
“Suction“ max. 1100 Watt
for “processing equipment“ connected
max. permissible 1900 Watt
Connected load:
Rated input power: max. 3 000 Watt
Protective class: I
Pollution severity: 2
Overvoltage category: II
Max. permissible leakage current
0.5 mA
Miniature circuit breaker:
2 x 16 A 100 - 120 Volt
2 x 16 A 230 Volt
Environmental conditions:
Permissible indoors.
Permissible ambient temperature range
from 5°C to 40°C.
Permissible up to max. relative humidity
80%
