Instructions for use ELECTROmatic M/C and PM/PC
3 Description of the product | 3.5 Control panel (PM/PC only)
22 / 78
3.5 Control panel (PM/PC only)
Note
The ELECTROmatic M/C versions of the product have no control panel. An
LED on the rear of the device flashes when the ELECTROmatic M/C is ready
for use.
Control panel ELECTROmatic PM/PC
Display information ELECTROmatic PM/PC
Display information example 1
① Speed memory 1 ④ Speed factor and unit
② SAFEdrive active = yellow ⑤ Speed
③ Clockwise rotation = green
Display information example 2
① Speed memory 2 ④ Speed factor and unit
② SAFEdrive inactive = grey ⑤ Speed
③ Anticlockwise rotation = red
