Instructions for use ELECTROmatic M/C and PM/PC
4 Installation | 4.7 Installation position 4: Mount control panel as remote control (PM/PC only)
▶ Mount the control unit.
See also:
2 4.4 Installation position 1: Mount below a holder, Page 33
4.7.4 Mount control panel to cabinet/wall
Installation on a cabinet/wall
CAUTION
Damage to the dentist element.
Installations involving an intervention on the treatment unit might damage
components, which can interfere with the safe function and cause injury.
▶ Have installations involving an intervention on the treatment unit per-
formed by trained expert personnel only.
▶ Have the treatment unit subjected to a safety check after installation.
The following parts from the scope of delivery and the installations set are
needed:
▪ 1x Insert holder
▪ 1x Mounting bracket
▪ 1x Cover panel
45 / 78
