FUNCTION GROUP 10 – COMMUNICATION MODE
(DIAC OPTION BOARD REQUIRED) (Continued)
** Read only.
Function
No. Description Range/Code
Factory
Setting
10.04 Drive Status
0
0: Stop
1: Run
—
1
0: Forward
1: Reverse
2
0: Normal
1: Fault
3
0: JOG-LCL/REM Command Off
1: JOG-LCL/REM Command On
4
0: N/A
1: Preset Frequency 1
5
0: N/A
1: Preset Frequency 2
6
0: N/A
1: Preset Frequency 3
7
0: N/A
1: Preset Frequency 4
8
0: N/A
1: Preset Frequency 5
9
0: N/A
1: Preset Frequency 6
10
0: N/A
1: Preset Frequency 7
11
0: Jog Momentary Mode
1: Jog Latching Mode
12 Reserved
13
0: Local
1: Remote
14, 15 Reserved
10.05 Drive Status Description
00 Normal Operation
—
01 Short Circuit Trip
02 Current Limit
03 Current Limit Trip
04 Undervoltage Trip
05 Recovered Undervoltage Trip
06 Overvoltage Trip
07 Recovered Overvoltage Trip
08 Stop Mode
09 Flash Error
10 External Fault Trip (IODA)
11 IODA Error
12 Phase Loss Trip
13 Current Source Trip (IODA)
10.06 ** Communications Error Count — —
10.07 ** Motor Voltage — —
10.08 ** Motor Current — —
10.09 ** Bus Voltage — —
10.10 ** Motor Frequency — —
