KEB COMBIVERT F5 Operation Manual

130
v1.72 Crossover Reference
v1.72 Pa-
rameter
Description v3.33 Pa-
rameter
v3.33 Description
LF.97 Actual Output Frequency Diag. #3 Output Frequency
LF.98 Last Fault Diag. Log
LF.99 Inverter State Diag #1-6,10 Inverter Status
Ld.18 Field Weakening Corner LM25 Field Weakening Speed
Ld.19 Field Weakening Curve -
Ld.20 Stator Resistance LM21 Motor Rs
Ld.21 Sigma Inductance LM20 Motor Ls
Ld.22 Rotor Resistance LM22 Motor Rr
Ld.23 (IM) Magnetizing Inductance LM23 Motor Lm
Ld.23 (PM) Maximum Inductance LM26 Maximum Ls
Ld.24 Motor Control LM30 Motor Control
Ld.25 Vmax Regulation LM31 Vmax Regulation
Ld.26 Rotor Position Mode LM27 Motor Inductance Mode
Ld.27 KP Current LM32 Kp Current
Ld.28 KI Current LM33 Ki Current
Ld.29 Acceleration Torque LC40 Acceleration Torque
Ld.30 System Inertia LC41 System Inertia
Ld.31 FFTC Filter LC42 FFTC Filter
Ld.32 FFTC Gain LC43 FFTC Gain
Ld.33 Torque Command Filter LC44 Torque Command Filter
US.1 Password ‘Pass’ hotkey
option from
Prog. Menu
US.3 Default All LF Parameters CH01
US05
Default Parameters
Load Conguration
US.4 Load Conguration US05 Load Conguration
US.10 Select Conguration US03 Motor Type
US.16 E.OL2 Function LX07 Carrier Frequency Handling
US.17 Pre-torque Timer Ramp Up LT02 Control Hold Off
US.18 Pre-torque Timer Ramp Down -
US.20 Max. Speed for Max. KI LC13
LC15
Speed for Max KI Accel
Speed for Max KI Decel
US.21 Speed for Min. KI LC14
LC16
Speed for Min KI Accel
Speed for Min KI Decel
US.22 Speed Dependent KP Gain -
US.23 Min. KP Gain at High Speed LC25 KP High Speed
US.24 KD Speed Gain -
US.25 Phase Current Check LX08 Phase Current Check
US.28 Analog Input Noise Clamp LA04 AnIn 1 Dead Band
US.29 HSP5 Watchdog Time LX09 SerCom. Watchdog Time
US.33 EdOH Function LX10 EdOH Function
US.34 Analog Pattern Gain LA05 AnIn 1 Gain
