v1.72 Crossover Reference
v1.72 Pa-
rameter
Description v3.33 Pa-
rameter
v3.33 Description
US.35 Reference Splitting LX11 Reference Splitting
US.36 External Serial Comm. Baud Rate Fb11/LX12 Baud Rate
US.37 Test Function LX06 Function Test
US.83 Encoder 2 Output PPR LE35 Encoder Output PPR
US.84 Analog Out 2 Signed LA36 AnOut2 Function
di.00 Input Type LI01 Type of Input
di.03 Noise Filter LI02 Digital Input Filter
do.42 Output Inversion LO01 Output Inversion
do.80 Output X2A.18 LO05 Output Function O1
do.81 Output X2A.19 LO10 Output Function O2
do.82 Output X2A.24/26 LO15 Output Function RLY1
do.83 Output X2A.27/29 LO20 Output Function RLY2
LP.1 One Floor Positioning LP01 Position Control
LP.2 Minimum Slowdown Distance LP02 Minimum Slowdown Distance
LP.3 Slowdown Distance LP03
LP04
High Speed Slowdown
Short Floor Slowdown Distance
LP.4 Correction Distance LP05 Correction Distance
LP.12 Current Position Diagnostic
Screen #10
Elevator Position
LP.21 Scaling Increments High LP06 Scaling Increments High
LP.22 Scaling Increments Low LP07 Scaling Increments Low
LP.23 Scaling Distance LP08 Scaling Distance
ru.00 Inverter State DG02 Inverter State
ru.02 Ramp Output Speed DG03 Command Speed
ru.03 Actual Frequency Display DG17 Output Frequency
ru.09 Encoder 1 Speed DG07 Motor Speed
ru.11 Set Torque Display DG16 Command Torque
ru.12 Actual Torque Display DG05 Actual Torque
ru.13 Actual Utilization DG46 Drive Load
ru.14 Peak Utilization DG47 Peak Load
ru.15 Apparent Current DG06 Motor Current
ru.16 Peak Apparent Current DG31 Peak Current
ru.18 Actual DC Voltage DG08 DC Volts
ru.19 Peak DC Voltage DG30 Peak DC Volts
ru.20 Output Voltage DG18 Output Voltage
ru.21 Input Terminal State DG01/Diag. #4 Input Status
ru.26 Active Parameter Set DG19/Diag. #4 Parameter Set
ru.27 AN1 Pre-Amplier Display DG20/Diag. #5 Raw Pattern
ru.28 AN1 Post Amplier Display DG21/Diag. #5 Processed Pattern
ru.29 AN2 Pre-Amplier Display DG33/Diag. #5 Raw Pretorque
